14/26 Automation products
HMI XVH300
Visualization
2010 CA08103002Z-EN
General
Front design Standard front with standard
membrane
Standard front with standard
membrane
Standard front with standard
membrane
Degree of protection
Front IP65 IP65 IP65
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Rear IP20 IP20 IP20
Approvals
Approvals cUL cUL cUL
Explosion protection
(According to ATEX 94/9/EC)
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Additional mounting bracket set
required for flush mounting
(￫Accessories)
Applied standards and directives
EMC (relevant for CE) EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61131-2
Explosion protection (relevant for CE) EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
EN 60079-0, EN 61241-1,
EN 13463
Safety EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950
Product standards EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2
Weight Approx. 1.7 kg Approx. 1.7 kg Approx. 1.7 kg
Environmental Conditions
Temperature
Operation 0 – 50°C 0 – 50°C 0 – 50°C
Storage/transport -20 – 60°C -20 – 60°C -20 – 60°C
Relative humidity 10 - 95%, non-condensing 10 - 95%, non-condensing 10 - 95%, non-condensing
Impact resistance To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27
Vibration To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6
XVH-340-57BAS-1-10 XVH-340-57CAN-1-10 XVH-340-57MPI-1-10
