14/32 Automation products
HMI-PLC XVS400
Visualization
2010 CA08103002Z-EN
VisualizationHMI-PLCXVS400
XVS-440-57MPI-1-10 XVS-430-57MPI-1-10 XVS-460-57MPI-1-10 XVS-450-57MPI-1-10
Display
Screen diagonal/type 5.7" CSTN LCD (color) 5.7" TFT LCD (color)
Resolution QVGA (320 × 240 pixels or 240 × 320 pixels in portrait format)
Visible screen area 115 mm x 86 mm 115 mm x 86 mm 115 mm x 86 mm 115 mm x 86 mm
Color resolution (grayscale or color) 256 colors 256 colors Adjustable: 65536 or
256 colors
Adjustable: 65536 or
256 colors
Contrast ratio Normally 35:1 Normally 35:1 Normally 400:1 Normally 400:1
Brightness Normally 150 cd/m² Normally 150 cd/m² Normally 350 cd/m² Normally 350 cd/m²
Backlight 1 x CCFL, dimmable via
software
1 x CCFL, dimmable via
software
LED, dimmable via
software
LED, dimmable via
software
Lifespan of backlight Normally 50000 h Normally 50000 h Normally 40000 h Normally 40000 h
Resistive touch protective screen – Touch sensor
(glass with membrane)
– Touch sensor
(glass with membrane)
Infra-red touch protective screen Laminated safety glass,
non-reflective
– Laminated safety glass,
non-reflective
–
Operation
Technology Infra-red touch,
47 x 31 logic channels
Resistive touch,
4-conductor
Infra-red touch,
47 × 31 logic channels
Resistive touch,
4-conductor
System
Processor RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz
Internal memory
DRAM (OS, program and data memory) 64 MByte 64 MByte 64 MByte 64 MByte
FLASH (can be used for data backup) Approx. 1.5 MByte available
NVRAM (Retain data) Approx. 32 kByte available
External memory
CF slot 1 x CompactFlash card type I/II for operating system, programs and data
Real-time clock (battery backup)
Battery Zero maintenance Zero maintenance Zero maintenance Zero maintenance
Backup time at zero voltage Normally 10 years Normally 10 years Normally 10 years Normally 10 years
Operating system Windows CE Windows CE Windows CE Windows CE
Engineering
Visualization software GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM GALILEO/EPAM
PLC programming software XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2 XSOFT-CODESYS-2
Interfaces, communication
Ethernet 100 Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T
System port RS232, not isolated (D-sub 9-pin, UNC)
CAN – – – –
PROFIBUS PROFIBUS galvanically isolated, max. 1.5 MBit/s (D-sub 9-pin socket, UNC)
USB Host USB 2.0 (1.5/12 MBit/s), not isolated
USB device USB 1.1, not isolated
Power supply
Nominal voltage 24 V DC SELV (safety extra low voltage)
Permissible voltage R.m.s.: 20.4 – 28.8 V DC (nominal voltage -15 %/+20 %)
Absolute with ripple: 19.2 – 30.0 V DC
35 V DC for a duration < 100 ms
Voltage dips 20 ms from nominal
voltage (24 V DC),
2 ms from undervoltage
(20.4 V DC)
20 ms from nominal
voltage (24 V DC),
2 ms from undervoltage
(20.4 V DC)
20 ms from nominal
voltage (24 V DC),
2 ms from undervoltage
(20.4 V DC)
20 ms from nominal
voltage (24 V DC),
2 ms from undervoltage
(20.4 V DC)
Input power Max. 19 W
(Normally 12 W)
Max. 19 W
(Normally 12 W)
Max. 19 W
(normally 12 W)
Max. 19 W
(normally 12 W)
Protection against polarity reversal Yes Yes Yes Yes
Fuse Yes (fuse not accessible)
Potential isolation No (0V connection to housing potential)
