Automation products Modular PLC 14/37
XV101 text display 1
Always in conjunction
with XC100-XV and XI/OC
(MMI-PLC)
Displays: 4 lines ×
20 characters (or 8 × 40)
LCD display with STN
technology
9 (or 15) function keys with
insert strips
Numerical key block and
arrow keys
Controller status LED
￫Page 14/38
XC100 2
Modular PLC
8 digital inputs
6 digital outputs
4 interrupt inputs
CANopen fieldbus interface
RS232 interface
Locally expandable
with XI/OC
Can be combined
with XV text displays
￫Page 14/38
XI/OC I/O modules 3
Space-optimized input/
output modules
Local extension on
XC100/200
Digital, analog, technology,
counter and communica-
tion cards
XI/OC modules can be
exchanged without the
need to undo wiring
￫Page 14/39
Module backplane 4
XI/OC backplane
For connecting the
XC100/200 controller and
the XI/OC modules with the
top-hat rail
￫Page 14/40
XC200 5
Modular PLC with Ethernet
interface
8 digital inputs
6 digital outputs
2 counters
2 interrupt inputs
1 incremental input
CANopen fieldbus interface
Web server
RS232 interface
Locally expandable with
XI/OC
￫Page 14/38
Battery 6
￫Page 14/41
Memory card
( multi-media card) 7
Memory for program,
operating system, recipes,
and visualization texts
￫Page 14/41
XI/OC terminal block 8
Connection options through
spring-loaded or screw
terminals
Exchange/remove without
disconnecting wiring
￫Page 14/40
XC121 9
Compact PLC
2 CANopen interfaces
RS232 interface
RS232/RS485 interface
MMC Memory card
OPC server
￫Page 14/38
EXT121-1 10
Expansion for compact PLC
10 digital inputs, of which,
6 interrupt inputs
8 digital outputs
6 analog inputs:
2 Pt100 RTD,
2 x 0-10 V, 2 x 0-20 mA
2 analog outputs 0 - 10 V
￫Page 14/38
