Description
Part No.
Article No.
Price
See price
list
Std. pack
Information relevant for export to North America
Communication cards
PROFIBUS-DP master module
XIOC-NET-DP-M
257908
1
off
Product Standards IEC: see Technical Data; UL508;
CSA-C22.2 No. 0-M; CSA-C22.2
No. 142-M; CE marking
UL File No.
E135462
UL CCN
NRAQ
CSA File No.
012528
CSA Class No.
2252-01
NA Certification
UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
PROFIBUS-DP slave module
XIOC-NET-DP-S
286419
Suconet K master module
XIOC-NET-SK-M
289982
Serial interfaces
RS232C, RS485, RS422
Modes of operation:
Transparent mode
Modbus master/slave
SUCOM-A
Suconet-K slave
XIOC-SER
267191
Serial interfaces
RS232C, RS485, RS422
Modes of operation:
Transparent mode
Modbus master/slave
SUCOM-A
DNP protocol
XIOC-TC1
135265
1
off
NA Certification
Request filed for UL and CSA
Accessories
Terminals
One 18 pole terminal plug is required for each digital and
analog module.
–
18-
pin connector with spring-cage
terminal for digital or analog I/O.
XIOC-TERM-18T
258104
10
off
NA Certification
Request filed for UL and CSA
–
18-
pin connector with screw terminals
for digital or analog I/O.
XIOC-TERM-18S
258102
–
30
pin connector for counter module,
with 4 m cable
XIOC-1CNT-100KHZ
XIOC-2CNT-100KHZ
XIOC-TERM30-CNT4
262248
1
off
–
40
pin connector for digital module,
with 4 m cable
XIOC-32DI
XIOC-32DO
XIOC-TERM32
267414
Module backplane
Basic backplane for mounting
XC100/200 on top-hat rail, can be
expanded
Width: 2 slots for controller
XIOC-BP-XC
260792
1
off
Product Standards IEC: see Technical Data; UL508;
CSA-C22.2 No. 0-M; CSA-C22.2
No. 142-M; CE marking
UL File No.
E135462
UL CCN
NRAQ
CSA File No.
012528
CSA Class No.
2252-01
NA Certification
UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Expansion backplane for mounting
XI/OC modules on top-hat rail,
can be expanded
Width: 2 slots for XI/OC modules
XIOC-BP-2
260794
1
off
Basic backplane for mounting
XC100/200 on top-hat rail, can be
expanded
Width: 3 slots for controller and one
XI/OC module
XIOC-BP-XC1
260793
1
off
Expansion backplane for mounting
XI/OC modules on top-hat rail,
can be expanded
Width: 3 slots for XI/OC modules
XIOC-BP-3
260795
1
off
Expansion backplane for mounting
XI/OC modules on top-hat rail,
can be expanded
Width: 3 slots for XI/OC modules
Note: Module Backplane for expansion
with up to 15 modules, must be plugged
into the 6th slot
XIOC-BP-EXT
274291
1
off
