14/46 Automation products
PLCs
2010 CA08103002Z-EN
Modular PLCs
COM2 (RS232/RS485) without handshake lines
Baud rate kbit/s Transparent mode
(setting through function blocks)
0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6
Character formats 8E1, 8O1, 8N1, 8N2, 7E2, 7O2, 7N2, 7E1
(setting through function blocks)
Potential isolation No
Bus termination External, for RS485
CAN1/CAN2 interface
Baud rate kbit/s 10 … 500
Potential isolation No
Stations 126
Bus termination Adjustable for each interface (CAN1/CAN2)
PDO type Asyn., cyc., acyc.
Power supply of local inputs/outputs (24 VQ/0 VQ)
Input voltage V DC 24
Voltage range V DC 19.2 - 30, observe polarity
Potential isolation
Between power supply and CPU voltage Yes
Overvoltage protection Yes
XC-CPU121-2C256K
