Automation products

PLCs

2010

CA08103002Z-EN

www.eaton.com

Modular PLCs

14/43

Interfaces

Serial interface (RS232)

without handshake lines

Baud rate

kbit/s Max. 57.6

Max. 57.6

Max. 57.6

Max. 57.6

Connections

RJ45

RJ45

RJ45

RJ45

Potential isolation

No

No

No

No

CANopen

Maximum data transfer rate

bit/s

500000

500000

500000

500000

Potential isolation

Yes

Yes

Yes

Yes

Device profile

To DS 301 V4

To DS 301 V4

To DS 301 V4

To DS 301 V4

PDO type

Asyn., cyc., acyc.

Asyn., cyc., acyc.

Asyn., cyc., acyc.

Asyn., cyc., acyc.

Connection

Plug-in terminal block

Plug-in terminal block

Optical fiber interface,

wavelength 660 mm,

plug e.g. HFBR-4516

Agilent Technologies

Plug-in terminal block

Bus terminating resistors

External

External

External

External

Stations

Number Max. 126

Max. 126

Max. 126

Max. 126

Watchdog

Yes

Yes

Yes

Yes

RTC (real-time clock)

Yes

Yes

Yes

Yes

Power supply of local inputs/outputs

(24

V

Q

/0

V

Q

)

Input voltage

V DC 24

24

24

24

Voltage range

V DC 19.2 - 30, observe polarity 19.2 - 30, observe polarity 19.2 - 30, observe polarity 19.2 - 30, observe polarity

Potential isolation

Between power supply and

CPU voltage

Yes

Yes

Yes

Yes

Overvoltage protection

Yes

Yes

Yes

Yes

Protection against polarity reversal

Yes

Yes

Yes

Yes

Digital inputs

Input current for channel at rated voltage

mA Normally 3.5

Normally 3.5

Normally 3.5

Normally 3.5

Heat dissipation for channel

Normally 85 m W Normally 85 m W Normally 85 m W Normally 85 m W

Voltage level to IEC/EN 61131-2

Limit value type 1

Low < 5 V DC,

High > 15 V DC

Low < 5 V DC,

High > 15 V DC

Low < 5 V DC,

High > 15 V DC

Low < 5 V DC,

High > 15 V DC

Input delay

OFF → ON

ms

Normally 0.1

Normally 0.1

Normally 0.1

Normally 0.1

ON → OFF

ms

Normally 0.1

Normally 0.1

Normally 0.1

Normally 0.1

Inputs

Number 8 (of which 4 interrupt

inputs)

8 (

of which 4 interrupt

inputs)

8 (

of which 4 interrupt

inputs)

8 (

of which 4 interrupt

inputs)

Channels with the same reference

potential

Number 8

8

8

8

Status indication

LED

LED

LED

LED

Digital outputs

Channels

Number 6

6

6

6

Heat dissipation for channel

W 0.08

0.08

0.08

0.08

Load circuits

A

0.5

0.5

0.5

0.5

Output delay

OFF → ON

Normally 0.1 ms

Normally 0.1 ms

Normally 0.1 ms

Normally 0.1 ms

ON → OFF

Normally 0.1 ms

Normally 0.1 ms

Normally 0.1 ms

Normally 0.1 ms

Channels with the same reference

potential

Number 6

6

6

6

Status indication

LED

LED

LED

LED

Switching capacity

IEC/EN 60947-5-1,

utilization category

DC-13

IEC/EN 60947-5-1,

utilization category

DC-13

IEC/EN 60947-5-1,

utilization category

DC-13

IEC/EN 60947-5-1,

utilization category

DC-13

Duty factor

%

DF 100

100

100

100

Utilization factor

g

1

1

1

1

XC-CPU101- C64K-8DI-

6

DO(-XV)

XC-CPU101- C128K-8DI-

6

DO(-XV)

XC-CPU101-FC128K-8DI-

6

DO(-XV)

XC-CPU101- C256K-8DI-

6

DO(-XV)
