Modular PLCs
ModularPLCsPLCs
Description Part No.
Article No.
Price
Seeprice
list
Std. pack
XC100
• 24 V supply • Can be locally expanded with 15 XI/OC is remotely expandable
• The following accessories are required: terminals, backplane, battery
• Controller with 8 digital inputs (4 interrupt inputs) • 6 digital outputs; RS232 interface for programming and
communication • CANopen interface • slot for MMC memory card • optional expansion with text display •
RUN/STOP switch and LED indicators.
64 kByte user memory XC-CPU101-C64K-8DI-6DO
262152
1 off
128 kByte user memory XC-CPU101-C128K-8DI-6DO
262146
256 kByte user memory XC-CPU101-C256K-8DI-6DO
274399
Optical CAN interface:
128 kByte user memory
XC-CPU101-FC128K-8DI-6DO
289169
Operation with display XV-101-…
64 kByte user memory
XC-CPU101-C64K-8DI-6DO-XV
262247
Operation with display XV-101-…
128 kByte user memory
XC-CPU101-C128K-8DI-6DO-XV
262150
Operation with display XV-101-…
256 kByte user memory
XC-CPU101-C256K-8DI-6DO-XV
279280
Text display for XC100
• Backlit LCD • membrane keypad • 1 slot for XC100 • 3 spare slots for XI/OC modules • numerical keypad •
arrow keys • contrast setting adjustable via software
Operation with XC-CPU101-…-XV
4 lines x 20 characters, resolution 122 x 32 pixels, 9 function keys
XV-101-K42
262403
1 off
Operation with XC-CPU101-…-XV
8 lines x 40 characters, resolution 240 x 64 pixels, 15 function keys
XV-101-K84
262404
1 off
XC121
• Compact PLC • 24 V supply • 2 CANopen interfaces • RS232 interface for programming and communication
• second RS232/RS485 interface • Slot for MMC memory card • Connection through spring-cage terminal
blocks • OPC server
Can be locally expanded with I/O module XIO-EXT-121-1
256 kByte program memory, 244 kByte data memory
XC-CPU121-2C256K
290446
1 off
I/O expansion for XC121
• Expansion unit with digital and analog inputs/outputs • expandable with XI/OC signal modules
(except XIOC-NET-DP-M) • pluggable spring-cage terminals
Local I/O expansions for PLC XC121
10 digital inputs 24 V DC, of which 6 interrupt
8 digital inputs/outputs 24 V DC, 0.5 A
2 analog inputs 0 - 10 V
2 analog inputs 0 - 20 mA
2 analog inputs Pt100 RTD
2 analog outputs 0 - 10 V
XIO-EXT121-1
290450
1 off
XC200
• 24 V supply • Can be locally expanded with 15 XI/OC is remotely expandable
• The following accessories are required: terminals, backplane, battery
• Controller with 8 digital inputs (2 counter, 2 interrupt inputs, 1 incremental input) • 6 digital outputs; Ethernet
and RS232 interface for programming and communication • CANopen interface • slot for memory card
(MMC) XC-CPU202 (MMC and SD) • USB interface • RUN/STOP switch and LED indicators
256 kByte user memory XC-CPU201-EC256K-8DI-6DO
262155
1 off
2 MByte user memory XC-CPU201-EC512K-8DI-6DO
262157
256 kByte user memory
Integrated web server
XC-CPU201-EC256K-8DI-6DO-XV
262156
2 MByte user memory,
Integrated web server
XC-CPU201-EC512K-8DI-6DO-XV
262158
4 Mbyte user memory, integrated Web server XC-CPU202-EC4M-8DI-6DO-XV
134238
Information relevant for export to North America
Product Standards IEC: see Technical Data; UL508; CSA-C22.2 No. 0-M; CSA-C22.2 No. 142-M; CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
