Visualization, XV-Dimensions
HMI-PLC XVS400
Standard membrane Standard membrane Standard membrane
(fully laminated)
Standard membrane Standard membrane
(fully laminated)
Standard membrane
IP65 IP65 IP65 IP65 IP65 IP65
Additional mounting bracket set required for flush mounting (￫Page 14/12)
IP20 IP20 IP20 IP20 IP20 IP20
cUL cUL cUL cUL cUL cUL
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
Additional mounting bracket set required for flush mounting (￫Page 14/12)
EN 61000-6-2, EN 61000-6-4, EN 61131-2
EN 60079-0, EN 61241-1, EN 13463
EN 60950/UL 60952 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950 EN 60950/UL 60950
EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2
Approx. 2.6 kg Approx. 3.7 kg Approx. 3.7 kg Approx. 4.1 kg Approx. 4.1 kg Approx. 5.8 kg
0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C
-20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27 To IEC 68-2-27
To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6 To IEC 68-2-6
XVS-460-84MPI-1-10 XVS-440-10MPI-1-10 XVS-430-10MPI-1-10 XVS-440-12MPI-1-10 XVS-430-12MPI-1-10 XVS-460-15MPI-1-10
14/35
XVM-4...
21.5 55.3 37.2 o 252
o
240
