14/30 Automation products
HMI-PLC XV400
Visualization
2010 CA08103002Z-EN
Power supply
Nominal voltage 24 V DC SELV (safety extra low voltage)
Permissible voltage R.m.s.: 20.4 – 28.8 V DC (rated operating voltage -15 %/+20 %)
Absolute with ripple: 19.2 – 30.0 V DC
35 V DC for a duration < 100 ms
Voltage dips 20 ms from nominal voltage (24 V DC), 2 ms from undervoltage (20.4 V DC)
Input power Max. 24 W
(Normally 13 W)
Max. 24 W
(Normally 13 W)
Max. 24 W
(Normally 13 W)
Max. 24 W
(Normally 13 W)
Max. 24 W
(Normally 13 W)
Max. 24 W
(Normally 13 W)
Protection against polarity reversal Yes Yes Yes Yes Yes Yes
Fuse Yes (fuse not accessible)
Potential isolation No (0V connection to housing potential)
General
Front design Standard front
with standard
membrane
Satin-finish
brushed stain-
less steel
Standard front
with standard
membrane(fully
laminated)
Standard front
with standard
membrane
Satin-finish
brushed stain-
less steel
Standard front
with standard
membrane(fully
laminated)
Degree of protection
Front IP65 IP65, IP69K IP65 IP65 IP65, IP69K IP65
Additional
mounting
bracket set
required for
flush mounting
Observe
installation
instructions to
IP69K
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Observe
installation
instructions to
IP69K
Additional
mounting
bracket set
required for
flush mounting
Rear IP20 IP20 IP20 IP20 IP20 IP20
Approvals
Approvals cUL cUL cUL cUL cUL cUL
Explosion protection
(According to ATEX 94/9/EC)
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Applied standards and directives
EMC (relevant for CE) EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, EN 61131-2
Explosion protection (relevant for CE) EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
Safety EN 60950/UL 60950
Product standards EN 50178, EN 61131-2
Weight Approx. 1.9 kg Approx. 2.3 kg Approx. 1.9 kg Approx. 1.9 kg Approx. 2.3 kg Approx. 1.9 kg
Environmental Conditions
Temperature
Operation 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50 °C
Storage/transport -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60 °C -20 – 60 °C
Relative humidity 10 - 95%, non-condensing
Impact resistance To IEC 68-2-27
Vibration To IEC 68-2-6
XV-442-
57CQB-1-10
XV-442-
57CQB-1-20
XV-442-
57CQB-1-50
XV-432-
57CQB-1-10
XV-460-57TQB-
1-10
XV-460-57TQB-
1-50
XV-450-57TQB-
1-10
