Automation products
HMI-PLC XV400
Visualization
24 V DC SELV (safety extra low voltage)
R.m.s.: 20.4 – 28.8 V DC (rated operating voltage -15 %/+20 %)
Absolute with ripple: 19.2 – 30.0 V DC
35 V DC for a duration < 100 ms
20 ms from
rated operating
voltage
(24 V DC),
2 ms from
undervoltage
(20.4 V DC)
10 ms from nominal voltage (24 V DC), 5 ms from undervoltage (20.4 V DC)
Max. 26 W
(Normally 15 W)
Max. 32 W
(Normally 14 W)
Max. 32 W
(Normally 14 W)
Max. 32 W
(Normally 14 W)
Max. 32 W
(Normally 14 W)
Max. 32 W
(Normally 14 W)
Max. 32 W
(Normally 14 W)
Max. 44 W
(Normally 28 W)
Max. 44 W
(Normally 28 W)
Yes Yes Yes Yes Yes Yes Yes Yes Yes
Yes (fuse not accessible)
No (0V connection to housing potential)
Standard front
with standard
membrane
Standard front
with standard
membrane
Satin-finish
brushed
stainless steel
Standard front
with standard
membrane(fully
laminated)
Standard front
with standard
membrane
Satin-finish
brushed
stainless steel
Standard front
with standard
membrane(fully
laminated)
Standard front
with standard
membrane
Satin-finish
brushed
stainless steel
IP65 IP65 IP65 IP65 IP65 IP65 IP65 IP65 IP65
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20 IP20
cUL cUL cUL cUL cUL cUL cUL cUL cUL
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 2G Ex px II
IP5x:
Zone 1,
category 2G
Zone 2,
category 3G
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 2G Ex px II
IP5x:
Zone 1,
category 2G
Zone 2,
category 3G
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II
T70°C IP5x:
Zone 22,
category 3D
II 3D Ex II T70°C
IP5x:
Zone 22,
category 3D
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Zone 1, Cate-
gory 2G and
Zone 2, Cate-
gory 3G: Only
when flush-
mounted in a
pressurized
enclosure!
Max. permissi-
ble excess
pressure:
10 mbar con-
tinuous
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Zone 1, Cate-
gory 2G and
Zone 2, Cate-
gory 3G: Only
when flush-
mounted in a
pressurized
enclosure!
Max. permissi-
ble excess
pressure:
10 mbar con-
tinuous
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
Additional
mounting
bracket set
required for
flush mounting
EN 61000-6-2, EN 61000-6-4, EN 61131-2
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463,
EN 1127-1,
EN 60079-2
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463,
EN 1127-1,
EN 60079-2
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60079-0,
EN 61241-1,
EN 13463
EN 60950/UL 60950
EN 50178, EN 61131-2
Approx. 3.0 kg Approx. 4.1 kg Approx. 5.3 kg Approx. 4.1 kg Approx. 4.5 kg Approx. 5.7 kg Approx. 4.5 kg Approx. 6.2 kg Approx. 7.5 kg
0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C 0 – 50°C
-20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C -20 – 60°C
10 - 95%, non-condensing
To IEC 68-2-27
To IEC 68-2-6
XV-460-84TVB-
1-10
XV-440-10TVB-
1-10
XV-440-10TVB-
1-20
XV-440-10TVB-
1-50
XV-430-10TVB-
1-10
XV-440-12TSB-
1-10
XV-440-12TSB-
1-20
XV-440-12TSB-
1-50
XV-430-12TSB-
1-10
XV-460-15TXB-
1-10
XV-460-15TXB-
1-50
