Visualization, XV-Dimensions
HMI-PLC XVS400
2010
CA08103002Z-EN
www.eaton.comGeneral
Front design
Standard membrane
Standard membrane
(
fully laminated)
Standard membrane
Standard membrane
(
fully laminated)
Degree of protection
Front
IP65
IP65
IP65
IP65
Additional mounting bracket set required for flush mounting (￫Page 14/12)
Rear
IP20
IP20
IP20
IP20
Approvals
Approvals
cUL
cUL
cUL
cUL
Explosion protection
(
According to ATEX 94/9/EC)
II 3D Ex II T70°C IP5x:
Zone 22, Category 3D
Additional mounting bracket set required for flush mounting (￫Page 14/12)
Applied standards and directives
EMC (relevant for CE)
EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, EN 61131-2
Explosion protection (relevant for CE)
EN 60079-0, EN 61241-1, EN 13463
Safety
EN 60950/UL 60950
EN 60950/UL 60950
EN 60950/UL 60950
EN 60950/UL 60951
Product standards
EN 50178, EN 61131-2
EN 50178, EN 61131-2
EN 50178, EN 61131-2
EN 50178, EN 61131-2
Weight
Approx. 1.8 kg
Approx. 1.8 kg
Approx. 1.8 kg
Approx. 1.8 kg
Environmental Conditions
Temperature
Operation
0 – 50
°C
0 – 50
°C
0 – 50
°C
0 – 50
°C
Storage/transport
-20 – 60
°C
-20 – 60
°C
-20 – 60
°C
-20 – 60
°C
Relative humidity
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
10 – 95%,
non-condensing
Impact resistance
To IEC 68-2-27
To IEC 68-2-27
To IEC 68-2-27
To IEC 68-2-27
Vibration
To IEC 68-2-6
To IEC 68-2-6
To IEC 68-2-6
To IEC 68-2-6
XVS-440-57MPI-1-10
XVS-430-57MPI-1-10
XVS-460-57MPI-1-10
XVS-450-57MPI-1-10
Dimensions
XV-..., XVH-3..., XVS-4..., MFD4...
Mounting dimensions
Part No.
a
b
c
d
e
f
XV-102-…-35...
136
100
25
5
123
87
XV-102-…-57...
170
130
34
5
157
117
XV-102-…-70...
210
135
33
5
197
122
XV-2…-57...
212
156
50
5
198
142
MFD4...
212
156
54
5
198
142
XVH-3…-57BAS... 212
156
55
5
198
142
XVH-3…-57CAN...
212
156
55
5
198
142
XVH-3…-57MPI...
212
156
55
5
198
142
XVH-3…-57SKS...
212
156
76
5
198
142
XVS-4…-57...
212
156
55
5
198
142
XVS-4…-84...
275
208
70
5
261
194
XVS-4…-10...
345
260
62
5
329
238
XVS-4…-12...
361
279
62
5
344
262
XVS-4…-15...
427
332
68
5
410
315
XV-4…-57...
212
156
76
5
198
142
XV-4…-84...
275
208
90
5
261
194
XV-4…-10...
345
260
88
5
329
238
XV-4…-12...
361
279
88
5
344
262
XV-4…-15...
427
332
94
5
410
315
a
b
c
d
e
f
