158 / 253
14/42
Automation products
PLCs
2010
CA08103002Z-EN
www.eaton.comModular PLCs
ModularPLCsPLCs
Technical data
XC-CPU101- C64K-8DI-
6
DO(-XV)
XC-CPU101- C128K-8DI-
6
DO(-XV)
XC-CPU101-FC128K-8DI-
6
DO(-XV)
XC-CPU101- C256K-8DI-
6
DO(-XV)
General
Standards
IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
Ambient temperature
°C
0 -
+55
0 -
+55
0 -
+55
0 -
+55
Storage
°C
-25
to +70
-25
to +70
-25
to +70
-25
to +70
Mounting position
Horizontal
Horizontal
Horizontal
Horizontal
Relative humidity, non-condensing
(
IEC/EN 60068-2-30)
% 10 - 95
10 - 95
10 - 95
10 - 95
Air pressure (in operation)
hPa
795 - 1080
795 - 1080
795 - 1080
795 - 1080
Vibration resistance
10 - 57
Hz ±0.075 mm
57 - 150
Hz ±1.0 g
10 - 57
Hz ±0.075 mm
57 - 150
Hz ±1.0 g
10 - 57
Hz ±0.075 mm
57 - 150
Hz ±1.0 g
10 - 57
Hz ±0.075 mm
57 - 150
Hz ±1.0 g
Mechanical shock resistance
15
g/11 ms
15
g/11 ms
15
g/11 ms
15
g/11 ms
Overvoltage category
II
II
II
II
Pollution degree
2
2
2
2
Degree of Protection
IP20
IP20
IP20
IP20
Rated insulation voltage
U
i
V
500
500
500
500
Emitted interference
EN 61000-6-4, Class A EN 61000-6-4, Class A EN 61000-6-4, Class A EN 61000-6-4, Class A
Interference immunity
EN 61000-6-2
EN 61000-6-2
EN 61000-6-2
EN 61000-6-2
Battery (lifespan)
Normally 5 years
Normally 5 years
Normally 5 years
Normally 5 years
Weight
kg
0.23
0.23
0.23
0.23
Terminals
Plug-in terminal block
Plug-in terminal block
Plug-in terminal block
Plug-in terminal block
Terminal capacity
Screw terminals
Flexible with ferrule
mm
2
0.5 - 1.5
0.5 - 1.5
0.5 - 1.5
0.5 - 1.5
Solid
mm
2
0.5 - 2.5
0.5 - 2.5
0.5 - 2.5
0.5 - 2.5
Spring-cage terminal
Flexible
mm
2
0.34 - 1.0
0.34 - 1.0
0.34 - 1.0
0.34 - 1.0
Solid
mm
2
0.14 - 1.0
0.14 - 1.0
0.14 - 1.0
0.14 - 1.0
Electromagnetic compatibility (EMC)
￫Page 14/58
Power supply
Mains failure duration
ms
10
10
10
10
Repetition rate
s
1
1
1
1
Input voltage
V DC 24
24
24
24
Permissible range
V DC 20.4…28.8
20.4…28.8
20.4…28.8
20.4…28.8
Input power
W Max. 26
Max. 26
Max. 26
Max. 26
Ripple
%
≦ 5
≦ 5
≦ 5
≦ 5
Maximum heat dissipation
(
without local I/O)
P
v
W 6
6
6
6
Overvoltage protection
Yes
Yes
Yes
Yes
Protection against polarity reversal
Yes
Yes
Yes
Yes
Mains filter (external)
Yes
Yes
Yes
Yes
Inrush current
x I
n
Not limited, (limiting only by a supply-side 24 V DC PSU)
Output voltage for signal modules
Rated value
V DC 5
5
5
5
Output current
A
3.2
3.2
3.2
3.2
Short-circuit rating
Yes
Yes
Yes
Yes
Isolated from supply voltage
No
No
No
No
CPU
Microprocessor
Infineon C164
Infineon C164
Infineon C164
Infineon C164
Memory
Program code/program data
kByte 64/64
128/128
128/128
256/256
Marker/retain data
kByte 4/4
8/8
8/8
8/8
Cycle time for 1 k of instructions
(
bits, bytes)
ms
< 0.5
< 0.5
< 0.5
< 0.5
