Automation products
PLCs
2010 CA08103002Z-EN
Modular PLCs 14/45
ModularPLCsPLCs
XC-CPU121-2C256K
General
Standards IEC/EN 61131-2
EN 50178
Ambient temperature °C 0 - +55
Storage °C -25 to +70
Mounting position Horizontal
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 10 - 95
Air pressure (in operation) hPa 795 - 1080
Vibration resistance Frequency 5 - 9 Hz; 3.5 mm amplitude
9 - 150Hz; 1.0 g constant acceleration
Mechanical shock resistance 15 g/11 ms
Overvoltage category II
Pollution degree 2
Degree of protection IP20
Rated insulation voltage Ui V 500
Emitted interference EN 61000-6-4
Interference immunity EN 61000-6-2
Backup time At least 72 hours
Weight kg 0.15
Electromagnetic compatibility (EMC) ￫Page 14/58
Connections
Supply voltage
Connection type -
Terminal capacity mm2 0.14 - 1 (AWG28-18)
COM1 interface
Connection type RJ45
COM2, CAN1, CAN2 interfaces
Connection type Spring-loaded terminal block, 6pole
Terminal capacity mm² 0.14 - 0.5 (AWG28-20)
Power supply
Input voltage V DC 24
Permissible range V DC 20.4…28.8
Input power W Max. 1.44
Input current mA 60
Ripple % ≦ 5
Maximum heat dissipation (without local I/O) Pv W 6
Overvoltage protection Yes
Protection against polarity reversal Yes
Inrush current x In No limitation (limited only by upstream 24 V DC power supply unit)
Supply failure bridging
Duration of power failure ms 10
Repetition rate s 1
External supply filter Part No.: XT-FIL-1, ￫Page 14/41
Memory
Program code/program data kByte 256/244
Marker/input/output/retain data kByte 16/4/4/8
Cycle time for 1 k of instructions (bits, bytes) ms < 0.3
Interfaces
Serial interface (RS232) without handshake lines
Baud rate kbit/s –
Baud rate kbit/s Programming
(character format: 8 data bits, No parity, 1 stop bit)
19.2, 38.4 (default), 57.6
Connector type RJ45
Potential isolation No
In transparent mode
Baud rate kbit/s 0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6, 115.2
Character formats 8E1, 8O1, 8N1, 8N2, 7E2, 7O2, 7N2, 7E1
Number of Send bytes for block 190
Number of Receive bytes for block 190
