14/50 Automation products
PLCs
2010 CA08103002Z-EN
Modular PLCs
Interfaces
Ethernet
Baud rate MBit/s 10/100 - Autodetect 10/100 - Autodetect 10/100 - Autodetect
Connector type RJ45 RJ45 RJ45
Potential isolation No No No
Serial interface (RS232) without handshake lines
Baud rate kbit/s Max. 115.2 Max. 115.2 Max. 115.2
Connector type RJ45 RJ45 RJ45
Potential isolation No No No
USB interface 1.0 1.0 2.0
CANopen
Maximum data transfer rate MBit/s 1 1 1
Potential isolation Yes Yes Yes
Device profile To DS 301 V4 To DS 301 V4 To DS 301 V4
PDO type Asyn., cyc., acyc. Asyn., cyc., acyc. Asyn., cyc., acyc.
Connection Plug-in terminal block Plug-in terminal block Plug-in terminal block
Bus terminating resistors External External internal
Stations Number Max. 126 Max. 126 Max. 126
Watchdog Yes Yes Yes
RTC (real-time clock) Yes Yes Yes
Power supply of local inputs/outputs (24 VQ/0 VQ)
Input voltage V DC 24 24 24
Voltage range V DC 19.2 - 30, observe polarity 19.2 - 30, observe polarity 19.2 - 30, observe polarity
Potential isolation
Between power supply and CPU voltage Yes Yes Yes
Between power supply and inputs/outputs No No No
Status indication LED LED LED
Terminals Plug-in terminal block Plug-in terminal block Plug-in terminal block
Overvoltage protection Yes Yes Yes
Protection against polarity reversal Yes Yes Yes
Digital inputs
Input current per channel at rated voltage mA Normally 3.5 Normally 3.5 Normally 3.5
Heat dissipation per channel Normally 85 m W Normally 85 m W Normally 85 m W
Voltage level to IEC/EN 61131-2
Limit value type 1 Low < 5 V DC,
High > 15 V DC
Low < 5 V DC,
High > 15 V DC
Low < 5 V DC,
High > 15 V DC
Input delay
OFF → ON ms Type 0.1 Type 0.1 Type 0.1
ON → OFF ms Type 0.1 Type 0.1 Type 0.1
Inputs Number 8, of which parameterizable: 2 counters, 50 kHz, 2 interrupt inputs, 1 incremental input
Channels with the same reference potential Number 8 8 8
Status indication LED LED LED
Digital outputs
Channels Number 6 6 6
Heat dissipation per channel W 0.08 0.08 0.08
Load circuits A 0.5 0.5 0.5
Output delay
OFF → ON Normally 0.1 ms Normally 0.1 ms Normally 0.1 ms
ON → OFF Normally 0.1 ms Normally 0.1 ms Normally 0.1 ms
Channels with the same reference potential Number 6 6 6
Status indication LED LED LED
Switching capacity IEC/EN 60947-5-1, utilization category DC-13
Duty factor % DF 100 100 100
Utilization factor g 1 1 1
XC-CPU201-EC256K-8DI-
6DO(-XV)
XC-CPU201-EC512K-8DI-
6DO(-XV)
XC-CPU202-EC4M-8DI-
6DO-XV
