Automation products
I/O expansions XI/OC
2010 CA08103002Z-EN
Modular PLCs 14/53
ModularPLCsI/OexpansionsXI/OC
XIOC-16DX
Power supply
Supply voltage 24 V DC (-15/+20%)
Ripple % ≦ 5
Overvoltage protection Yes
Protection against polarity reversal Yes
Potential isolation
Between power supply and I/O bus Yes
Between power supply and I/O No
Internal current consumption (5 V DC) mA Normally 80
Channels Number 16
Terminals Plug-in terminal block
Status indication LED
Inputs
Input type DC input
Input voltage V DC 24 V DC
Inputs Number 4, 12, configurable
Input current mA Normally 4
Voltage level to IEC 61131-2, limit value type 1
ON V ≧ 15 DC
OFF V ≦ 5 DC
Input delay
OFF → ON ms Normally 0.1
OFF → ON ms Normally 0.1
Outputs
Output type Transistor (source type)
Output voltage V DC 12/24 (-15…+20 %)
Output current A Normally 0.5
Outputs Number Max. 12, configurable
Short-circuit tripping current A Max. 1.2 over 3 ms for output
Lamp load W Max. 3
Drop-out delay (High → Low) μs Normally 100
Switching capacity IEC/EN 60947-5-1, utilization category DC-13
Short-circuit rating Yes
Parallel connection of outputs In groups 0 – 3, 4 – 7, 8 – 11;
Actuation of the outputs within a group only in the same program cycle
Number of outputs that can be switched in parallel Max. 3
Total maximum current A 2 for group
Weight kg 0.16
