173 / 253
Automation products
I/O expansions IX/OC
2010
CA08103002Z-EN
www.eaton.comModular PLCs
14/57
ModularPLCsI/Oexpansions IX/OC
XIOC-1CNT-100KHZ
XIOC-2CNT-100KHZ
XIOC-2CNT-2AO-INC
Inputs
Counter limits
0 - 4294967295 (32
bit)
0 - 4294967295 (32
bit)
0 - 4294967295 (32
bit)
Internal current consumption
mA
200
200
450
Frequency
kHz
100 (25
with four times
resolution)
100 (25
with four times
resolution)
400 (100
with four times
resolution)
Number of channels
1
2
2
Input voltage
V DC 12 - 24
12 - 24
–
Voltage for ON
V DC > 10
> 10
–
Voltage for OFF
VA/W < 4
< 4
–
Input current
mA
≧ 4
≧ 4
–
Differential input voltage
V DC ± 5
± 5
± 5
Voltage for ON
V DC 2 - 5
2 - 5
0.2 - 5
Voltage for OFF
V DC -5 - 8
-5 - 8
-5 - -0.2
Differential input current
mA
35
35
5
Minimum pulse width
μs
ON ≧ 4
OFF ≧ 4
ON ≧ 4
OFF ≧ 4
–
Potential isolation
With optocouplers
With optocouplers
–
Connection for external cabling
30-
pin plug:
XIOC-TERM30-CNT4
30-
pin plug:
XIOC-TERM30-CNT4
Plug-in terminal block
External cabling
Shielded, twisted pair cable Shielded, twisted pair cable Shielded, twisted pair cable
Outputs
Output type
Transistor (open collector)
Transistor (open collector)
Analog
External power supply
12/24
V DC (30 max.)
12/24
V DC (30 max.)
–
Minimum load current
mA
1
1
–
Maximum load current
I
e
mA
20
20
–
Max. leakage current
mA
0.5
0.5
–
Max. voltage drop at ON
V
1.5
1.5
–
Debounce OFF
OFF → ON
ms
≦ 1
≦ 1
–
OFF → ON
ms
≦ 1
≦ 1
–
Output channels
Number 2
4
2
Potential isolation
With optocouplers
With optocouplers
–
Output voltage
V DC –
–
-10 - 10
Resolution
bit
–
–
12
Conversion time
–
–
≦ 1 ms
Total errors
% –
–
Normally 0.4
Load resistance
–
–
≧ 1 kΩ
Connection for external cabling
30-
pin plug:
XIOC-TERM30-CNT4
30-
pin plug:
XIOC-TERM30-CNT4
Plug-in terminal block
External cabling
Shielded, twisted pair cable Shielded, twisted pair cable Shielded 2-core cable
Current per channel
mA
–
–
≦ 300
Power supply of encoders
–
–
5
V DC
Current consumption
mA
200
200
Max. 450
Weight
kg
0.16
0.16
0.18
