14/58 Automation products
I/O expansions XI/OC, EMC
2010 CA08103002Z-EN
Modular PLCs
ModularPLCsI/OexpansionsXI/OC,EMC
XT-FIL-1 XT-FIL-2
General
Standards IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
Ambient temperature °C 0 - +55 0 - +55
Storage °C -25 - +70 -25 - +70
Mounting position Vertical or horizontal Vertical or horizontal
Vibration resistance 10 - 57 Hz ± 0.075 mm
57 - 150 Hz ± 1.0 g
10 - 57 Hz ± 0.075 mm
57 - 150 Hz ± 1.0 g
Mechanical shock resistance 15 g/11 ms 15 g/11 ms
Impact strength 500 g /50 mm ±25 g 500 g/50 mm ±25 g
Overvoltage category II II
Pollution degree 2 2
Protection type IP20 IP20
Rated impulse withstand voltage Uimp V 850 850
Interference immunity EN 61000-6-2 EN 61000-6-2
Weight kg 0.1 0.1
Dimensions (W x H x D) mm 35 x 90 x 30 35 x 90 x 57
Terminals Screw terminals Screw terminals
Terminal capacity
Screw terminals
Flexible with ferrule mm 2 0.2 - 2.5 (AWG22 - 12) 0.2 - 2.5 (AWG22 - 12)
Solid mm 2 0.2 - 2.5 (AWG22 - 12) 0.2 - 2.5 (AWG22 - 12)
Power supply
Input voltage V DC 24 24
Permissible range V DC 20.4…28.8 20.4…28.8
Ripple % ≦ 5 ≦ 5
Mains overvoltage protection Yes Yes
Potential isolation
Between input voltage and PE Yes Yes
Between input voltage and output voltage No No
Between output voltage and PE Yes Yes
Rated value V DC 24 24
Output current A 2.2 12
General information on electromagnetic compatibility (EMC) of automation systems
Emitted interference EN 55011/22 Class A (VDE 0875, Part 11)
Interference immunity
ESD IEC/EN 61000-4-2 Contact discharge
Air discharge
4 kV
8 kV
RFI IEC/EN 61000-4-3 AM (80 %) 80 - 1000 MHz 10 V/m
Mobile phones/cellphones IEC/EN 61000-4-3 PM 800 - 960 MHz 10 V/m
Burst IEC/EN 61000-4-4 Mains/digital I/O (direct)
Analog I/O, fieldbus (capacitive coupling)
2 kV
1 kV
Surge IEC/EN 61000-4-5 Digital I/O, asymmetric, analog I/O, asymmetric, connection to shielding
Mains DC, asymmetric
Mains DC, symmetric
Mains AC, asymmetric
Mains AC, symmetric
0.5 kV
1 kV
1 kV
0.5 kV
2 kV
1 kV
Conducted interference,
induced by high-frequency fields
IEC/EN 61000-4-6;
2003
AM (80 %) 150 kHz - 80 MHz 3 V
