Compact PLCs 14/63
Basic device
EC4P 1
Expandable: Digital and analog inputs/
outputs and bus systems AS-Interface,
CANopen, PROFIBUS-DP, DeviceNet;
Ethernet optional
Bus system easyNet on board
24 V DC
12 digital inputs
4 of which usable as analog inputs
6 relay outputs (max. 10 A, UL) or
8 transistor outputs
1 analog output optional
Display and keypad optional
Screw and top-hat rail fixing
Screw terminals
￫Page 14/64
Remote text display 2, 3, 4
Consists of:
• Text display MFD-80..(-B) 2
• CANopen interface module
MFD-CP4-CO (order connection cable
EU4A-RJ45-CAB2 separately)
3
• Power supply unit/communication
card, including connection cable
(5 m, can be cut to desired length)
for EC4P
4
24 V DC = MFD-CP4-800
100 - 240 V AC = MFD-AC-CP4-800
Spring-cage terminals
￫Page 14/66
Bus modules
EASY204-DP 5
PROFIBUS-DP interface,
connection as slave
24 V DC
￫Page 14/66
EASY205-ASI 6
AS-Interface connection as slave,
24 V DC
￫Page 14/66
EASY221-CO 7
CANopen interface, 24 V DC
￫Page 14/66
EASY222-DN 8
DeviceNet interface, 24 V DC
￫Page 14/66
Output expansion
EASY202-RE 9
2 relay outputs (max. 10 A, UL)
Screw and top-hat rail fixing
Screw terminals
￫Page 14/65
I/O expansion modules
EASY406-DC-ME 10
24V DC
1 digital input
2 analog inputs (2 × 0-10 V or
2 × 0-20 mA or 2 × Pt100 RTD;
voltage inputs 0-10 V can optionally
be used as digital inputs)
1 analog output (0 - 10 V)
2 transistor outputs
Screw and top-hat rail fixing
Screw terminals
￫Page 14/65
EASY411-DC-ME 10
24V DC
1 digital input
6 analog inputs (2 × 0-10 V and
2 × 0-20 mA and 2 × Pt100 RTD;
voltage inputs 0-10 V can optionally
be used as digital inputs)
2 analog outputs (0 - 10 V)
2 transistor outputs
Screw and top-hat rail fixing
Screw terminals
￫Page 14/65
EASY6... 11
24V DC
12digital inputs
6 relay outputs (max. 10 A, UL) or
8 transistor outputs
Screw and top-hat rail fixing
Screw terminals
￫Page 14/65
EASY410... 13
24V DC
6 digital inputs
4 relay outputs (max. 10 A, UL) or
4 transistor outputs
Screw and top-hat rail fixing
Screw terminals
￫Page 14/65
Coupling module
EASY200-EASY 12
For remote connection of a digital I/O
expansion module through two-pole
connection cable (max. 30 m);
e.g. NYM 3 × 1.5 mm 2
￫Page 14/65
CANopen expansion modules
EC4E-221… 14
24 V DC
6 digital inputs
4 relay outputs or
4 transistor outputs
