14/68 Automation products
Accessories
2010 CA08103002Z-EN
Compact PLCs
Description For use with Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Network connection cables
Length: 0.3 m easyNet EASY-NT-30
256283
1 off Product Standards IEC/EN see Technical Data;
UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Length: 0.8 m easyNet EASY-NT-80
256284
Length: 1.5 m easyNet EASY-NT-150
256285
Bus termination resistor
8- pin, RJ45, 124 Ω
Connection to PIN 1
and PIN 2
easyNet EASY-NT-R
256281
2 off
Data cable
4 x 0.14 mm², twisted
pair, AWG 26
Length: 100 m
easyNet EASY-NT-CAB
256286
1 off UL File No. E135462
UL CCN NRAQ
NA Certification UL Listed
Degree of Protection IEC: IP 20, UL/CSA Type: -
Bus connector plug
8- pin, RJ45 easyNet EASY-NT-RJ45
256280
10 off Product Standards IEC/EN see Technical Data;
UL 508;
CSA C22.2 No. 142-M1987;
CSA C22.2 No. 213-M1987;
CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Crimping tool
– For RJ45 plug EASY-NT-
CAB
EASY-NT-
RJ45
EASY-RJ45-TOOL
256282
1 off
PROFIBUS-DP data cable
Twisted pair, without plug, 2-core,
2 x 0.64 mm²
(only suitable for fixed wiring)
100 m
ZB4-900-KB1
206983
100 m
PROFIBUS-DP bus connector plug
9- pin male
Cable entry, angled 90°
ZB4-209-DS2
206982
1 off
Metalized insulated housing
Maximum transfer rate 12 MBit/s
Integrated switch (accessible From
the outside) for the bus terminating
resistors
Terminal block for two cable entries,
with straight or 90° angled cable entry,
as required
ZB4-209-DS3
217820
1 off
Connection plug
Bus connector plug between base unit
and expansion unit/bus module
EASY-LINK-DS
221607
1 off UL/CSA certification not required
Fixing bracket
For screw fixing to mounting plate
3 fixing brackets
for easy400, 500, 600, 700, 800, EC4P,
ES4P
2 fixing brackets for easy200
3 fixing brackets for MFD-CP8…,
MFD-AC-CP8…
ZB4-101-GF1
061360
9 off UL/CSA certification not required
HPL14068EN
