Compact PLCs 14/69
Description For use with Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Telescopic clip
For use with 35 mm top-hat rail to IEC/EN
60715 for mounting depth compensation
when rear mounting in enclosures CI-K... and
panels.
Stepless adjustment via scale from
75 – 115 mm.
Screw and snap mounting
M22-TA
226161
1 off Product Standards IEC/EN 60947-5; UL 508;
CSA-C22.2 No. 14-05; CSA-
C22.2 No. 94-91; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Top-hat rail adapter for hinged inspection window
12 mm x 66 mm x 82 mm
Installation on hinged inspection window, for
front fitting of devices.
Complete set, consisting of 2 brackets and
4 screws
SKF-HA
233782
1 off UL/CSA certification not required
Hinged inspection window
94 mm x 77 mm x 25 mm (4 space units)
For use with easy500
SKF-FF4
233780
1 off UL/CSA certification not required
130 mm x 77 mm x 25 mm (6 space units)
For use with EASY700, EASY800, EC4P, ES4P
SKF-FF6
233781
Protective cover
Transparent
Protection against
accidental actuation
Sealable
Use without front frame
MFD-80… MFD-XS-80
265259
1 off Product Standards IEC/EN see Technical Data;
UL 508; CSA C22.2
No. 142-M1987; CSA C22.2
No. 213-M1987; CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Protective diaphragm
Transparent type for harsh
environmental conditions
and application in the food
industry
For increasing the degree of
protection to NEMA 4X for
MFD-80-B
MFD-80… MFD-XM-80
265258
1 off Product Standards IEC/EN see Technical Data;
UL 508; CSA C22.2
No. 142-M1987; CSA C22.2
No. 213-M1987; CE marking
UL File No. E135462
UL CCN NRAQ
CSA File No. 012528
CSA Class No. 2252-01 + 2258-02
NA Certification UL Listed, CSA certified
Degree of Protection
IEC: IP65, UL/CSA Type:°4X
Supply voltage
connection
Description For use with Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to
North America
Custom labeling, user program
• Custom labeling of multi-function display with labeling
software Labeleditor or
• Supply of multi-function display programmed with user
program
MFD-80-X
MFD-80-B-X
MFD-COMBINATION-*
265260
1 off UL/CSA certification not required
• Custom labeling of easy Control with labeling software
Labeleditor or supply of easyControls programmed
with user program
EC4P EC4-COMBINATION-*1)
107600
1 off
Notes Example for using the Labeleditor la beling software
Individually label your device in 4 stages:
– Download the labeling software: , keyword: "Labeleditor"
– Create a label template (menu-guided in the software)
– Mail the label template to the factory. The program automatically selects the correct e-mail address for the selected product and assigns a file
name, such as “EASY_12345.zip”. This file name is part of the article to be ordered (see Ordering examples).
– Send your order to your Eaton sales office or your electrical wholesaler.
Ordering example: MFD-Titan
MFD-80-B multi-function display with “company name”:
1 x MFD-COMBINATION-*
1 x MFD-80-B
1 x the file name “MFD_xxxxx.zip” issued by the Labeleditor
Ordering example: EC4P
EC4P-221-MTXD1 with “company name”:
1 x EC4-COMBINATION-*
1 x EC4P-221-MTXD1
1 x the file name “EC4P_xxxxx.zip” issued by the Labeleditor
