Compact PLCs

14/73

CompactPLCs

EC4P-…-MT…

Transistor outputs

Number

8

Rated operating voltage

U

e

V DC

24

Permissible range

U

e

V DC

20.4 - 28.8

Ripple

%

≦ 5

Supply current

At state ”0”

Normally.⁄

max.

mA

18/32

At state ”1”

Normally.⁄

max.

mA

24/44

Protection against polarity reversal

Yes (Caution: A short circuit will result if 0 V or GND

is applied to the outputs if the supply voltage is

connected to the wrong poles.)

Potential isolation

From power supply

Yes

To PC interface, memory card, network NET, easyLink

Yes

From the inputs

Yes

Rated operational current at state “1” DC

I

e

A

Max. 0.5

Lamp load without R

v

W

5

Residual current at state “0” for channel

mA

< 0.1

Max. output voltage

At state “0” with external load < 10 MΩ

V

2.5

At state “1” at I

e

= 0.5 A

V

U = U

e

-1

V

Short-circuit protection

Yes, electronic (Q1 – Q4), thermal (Q5 – Q8),

(

analysis via diagnostics input I16, I15)

Short-circuit tripping current for R

a

≦ 10 mΩ

A

0.7

≦ I

e

≦ 2 for output

Total short-circuit current

A

16

Peak short-circuit current

A

32

Thermal cutout

Yes

Max. operating frequency at constant resistive load R

L

< 100 kΩ

(

dependent on program and load)

Ops/h

40000

Parallel connection of outputs

With resistive load, inductive load with external suppressor circuit,

combination within a group

Group 1: Q1 to Q4

Group 2: Q5 to Q8

Number of outputs

max.

4

Max. total current

A

2 (

Caution! Outputs must be actuated simultaneously

and for the same duration.)

Output status indication

LCD display (if fitted)

Inductive load to EN 60947-5-1

Without outer suppressor circuit

T

0.95

= 1 ms, R = 48 Ω, L = 16 mH

Utilization factor

g

0.25

Duty factor

%

DF

100

Max. operating frequency f = 0.5 Hz

(

max. DF = 50 %)

Operations

1500

DC-13, T

0.95

= 72 ms, R = 48 Ω, L = 1.15 H

Utilization factor

g

0.25

Duty factor

%

DF

100

Max. operating frequency f = 0.5 Hz

(

max. DF = 50 %)

Operations

1500

T

0.95

= 15 ms, R = 48 Ω, L = 0.24 H

Utilization factor

g

0.25

Duty factor

%

DF

100

Max. operating frequency f = 0.5 Hz

(

max. DF = 50 %)

Operations

1500

With outer suppressor circuit

Utilization factor

g

1

Duty factor

%

DF

100

Max. operating frequency, max. duty factor

Operations

Depending on the suppressor circuit
