Automation products
I/O expansions
2010 CA08103002Z-EN
Compact PLCs 14/77
EC4E-221-6D4R1
Relay outputs
Number 4
Outputs in groups of 1
Parallel switching of outputs to increase performance Not permissible
Protection of an output relay Miniature circuit-breakers B16 or
fuse 8 A (T)
Potential isolation
From power supply Yes
From the inputs Yes
From PC interface, memory card, network NET, easyLink Yes
Safe isolation According to EN 50178 V AC 300
Basic insulation V AC 600
Lifespan, mechanical Operations x 106 10
Contacts
Conventional thermal current (10 A UL) A 8
Recommended for 12 V AC/DC load mA > 500
Short-circuit proof p.f. = 1, characteristic B16 at 600 A A 16
Short-circuit proof p.f. = 0.5 - 0.7; characteristic B16 at 900 A A 16
Rated impulse withstand voltage Uimp contact coil kV 6
Rated operating voltage Ue V AC 250
Rated insulation voltage Ui V AC 250
Safe isolation to EN 50178 between coil and contact V AC 300
Safe isolation to EN 50178 between two contacts V AC 300
Making capacity
AC-15, 230 V AC, 3 A Operations 300000
DC-13, 24 V DC, 0.1 Hz Operations 200000
Breaking capacity
AC-15, 250 V AC, 3 A (600 ops./h) Operations 300000
DC-13, L/R ≦ 150 ms, 24 V DC, 1 A (500 ops./h) Operations 200000
Filament bulb load
1000 W at 230/240 V AC Operations 25000
500 W at 115/120 V AC Operations 25000
Fluorescent lamp load
Fluorescent lamp load 10 x 58 W at 230/240 V AC
With series-connected electrical device Operations 25000
Uncompensated Operations 25000
Fluorescent lamp load 1 x 58 W at 230/240 V AC, conventionally compensated Operations 25000
Switching frequency
Mechanical operations x 106 10
Switching frequency Hz 10
Resistive load/lamp load Hz 2
Inductive load Hz 0.5
UL/CSA
Continuous current at 240 V AC A 10
Continuous current at 24 V DC A 8
AC
Control circuit rating codes (utilization category) B 300 Light Pilot Duty
Max. rated operational voltage V AC 300
Max. thermal continuous current p.f. = 1 at B 300 A 5
Max. make/break capacity p.f. ≠ 1 at B 300 VA 3600/360
DC
Control circuit rating codes (utilization category) R 300 Light Pilot Duty
Max. rated operational voltage V DC 300
Max. thermal continuous current p.f. at R 300 A 1
Max. make/break capacity at R 300 VA 28/28
