Automation products
Communication card
2010 CA08103002Z-EN
Compact PLCs 14/79
CompactPLCsCommunicationcard
MFD-CP4-CO
General
Standards EN 61000-6-1/-2/-3/-4, IEC 60068-2-6, IEC 60068-2-27
Dimensions (W x H x D) mm 75 x 58 x 36.2
Weight kg 0.16
Mounting Plug-fitted to the display fixing shaft
Terminal capacity
Power supply
Solid mm 2 0.5 - 2.5 (AWG 20 - 14)
Flexible with ferrule mm 2 0.5 - 1.5 (AWG 20 - 16)
Flat-blade screwdriver mm 3.5 x 0.6
Data cable
Solid mm 2 0.2 - 0.5 (AWG 24 - 20)
Ambient climatic conditions
Operating ambient temperature °C -25 - 55, low temperatures to IEC 60068-2-1,
high temperatures to IEC 60068-2-2
Condensation Prevent condensation by means of suitable measures
Storage °C -40 - 70
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 5 - 95
Air pressure (in operation) hPa 795 - 1080
Ambient mechanical conditions
Pollution degree 2
Protection type (IEC/EN 60529, EN50178, VBG 4) IP20
Vibrations (IEC/EN 60068-2-6)
Constant amplitude 0.15 mm Hz 10 - 57
Constant acceleration, 2 g Hz 57 - 150
Mechanical shock resistance (IEC/EN 60068-2-27)
semi-sinusoidal 15 g/11 ms
Shocks 18
Drop to IEC/EN 60068-2-31 Drop
height
mm 50
Free fall, packaged (IEC/EN 60068-2-32) m 1
Mounted position Vertical or horizontal
Electromagnetic compatibility (EMC)
Overvoltage category/pollution degree –
Electrostatic discharge (IEC/EN 61000-4-2, Level 3, ESD)
Air discharge kV 8
Contact discharge kV 6
Electromagnetic fields (RFI), to IEC EN 61000-4-2 V/m 10
Radio interference suppression EN 55011 Class B, EN 55022 Class B
Burst pulses (IEC/EN 61000-4-4, Level 3)
Supply cables kV 2
Signal cables kV 2
Surge pulses (IEC/EN 61000-4-5, Level 2) kV 0.5
Line-conducted interference (IEC/EN 61000-4-6) V 10
Insulation resistance
Clearance in air and creepage distances EN 50178, UL 508, CSA C22.2, No. 142
Insulation resistance EN 50178
Power supply
Rated operational voltage U e V 24 DC (-15⁄+20 %)
Permissible range V DC 20.4 - 28.8
Ripple % ≦ 5
Input current
At 24 V DC mA Normally 185
Voltage dips (IEC/EN 61131-2) ms 10
Heat dissipation at 24 V DC W 1.5
Interfaces
CANopen
Device profile To DS301V4
PDO type Asynchronous (event controlled)
Addresses 1 to 63 can be set through display
Baud rate/length kBd 10 kByte up to 1 MByte, Automatic detection
Manual setting via display possible.
Connections 6 pole spring-cage terminal
Terminal resistor Ω External 120
