Remote I/O XI/ON
14/85
Remote I/OXI/ONSelectionchart
Basic modules
XN-S3...-SBB
XN-S3...-SBC
XN-S4...-SBBC
XN-S4...-SBBS
XN-S4...-SBCS
XN-S4...-SBBS-CJ
XN-S6...-SBBSBB
XN-S6...-SBCSBC
XN-B3...-SBB
XN-B3...-SBC
XN-B4...-SBBC
XN-B6...-SBBSBB
XN-B6...-SBCSBC
XN-P3...-SBB
XN-P3...-SBB-B
XN-P4...-SBBC
XN-P4...-SBBC-B
Electronics modules
Digital input modules
XN-2DI-24VDC-P
●
●
XN-2DI-24VDC-N
●
●
XN-2DI-120/230VAC
●
●
XN-4DI-24VDC-P
●
●
XN-4DI-24VDC-N
●
●
XN-16DI-24VDC-P
●
●
XN-32DI-24VDC-P
●
XNE-8DI-24VDC-P
1)
XNE-16DI-24VDC-P
1)
Digital output modules
XN-2DO-24VDC-0.5A-P
●
●
XN-2DO-24VDC-0.5A-N
●
●
XN-2DO-24VDC-2A-P
●
●
XN-2DO-120/230VAC-0.5A
●
●
XN-4DO-24VDC-0.5A-P
●
●
XN-16DO-24VDC-0.5A-P
●
XN-32DO-24VDC-0.5A-P
●
XNE-8DO-24VDC-0.5A-P
1)
XNE-16DO-24VDC-0.5A-P
1)
Relay modules
XN-2DO-R-NC
● ●
XN-2DO-R-NO
● ●
XN-2DO-R-CO
●
Analog input modules
XN-1AI-I(0/4...20MA)
●
●
XN-2AI-I(0/4...20MA)
●
●
XN-1AI-U(-10/0...+10VDC)
●
●
XN-2AI-U(-10/0...+10VDC)
●
●
XN-2AI-Pt/Ni-2/3
●
●
XN-2AI-THERMO-PI
●
XN-4AI-U/I
●
XNE-8AI-U/I-4Pt/Ni
1)
Analog output modules
XN-1AO-I(0/4...20MA)
●
XN-2AO-I(0/4...20MA)
●
XN-2AO-U(-10/0...+10VDC)
●
XNE-4AO-U/I
1)
Technology modules
XN-1CNT-24VDC
●
XN-1RS232
●
XN-1RS485/422
●
XN-1SSI
●
XNE-1SWIRE
1)
XNE-2CNT-2PWM
1)
Supply modules
XN-BR-24VDC-D
●
2)
●
3)
●
2)
●
3)
XN-PF-24VDC-D
●
●
XN-PF-120/230VAC-D
●
●
Notes
1)
2)
3)
No base modules required
Base module for gateway supply
Base module for bus refreshing within the station
