Automation products
PLCs
2010 CA08103002Z-EN
Compact PLCs 14/71
CompactPLCsPLCs
EC4P-221... EC4P-222...
Power supply
Rated operational voltage Ue V 24 DC (-15/+20%) 24 DC (-15/+20%)
Permissible range V DC 20.4 - 28.8 20.4 - 28.8
Ripple % ≦ 5 ≦ 5
Input current
At rated voltage mA Normally 140 Normally 140
At rated operating voltage with load A – –
Voltage dips (IEC/EN 61131-2) ms 10 10
Heat dissipation W Normally 3.4 Normally 3.4
CPU
Microprocessor Infineon XC161 Infineon XC161
Memory
Program code/data kByte 256/14 segments of 16 KB each 256/14 segments of 16 KB each
Marker/input/output/retain data kByte 16/4/4/8 16/4/4/8
Cycle time for 1 k of instructions (bits, bytes) ms < 0.3 < 0.3
Interfaces
COM1 (RS232) without control cables
Data transfer rate for programming kBit/s 4.8, 9.6, 19.2, 38.4, 57.6, 115.2 (character format: 8 data bits, no parity, 1 stop bit)
Connections RJ45 bus RJ45 bus
Potential isolation None None
In the transparent mode
Baud rate kBit/s 0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6 0.3, 0.6, 1.2, 2.4, 4.8, 9.6, 19.2, 38.4, 57.6
Character formats 8E1, 8O1, 8N1, 8N2, 7E2, 7O2, 7N2, 7E1 8E1, 8O1, 8N1, 8N2, 7E2, 7O2, 7N2, 7E1
Number of transmission bytes in a block 190 Byte 190 Byte
Number of received bytes in a block 190 Byte 190 Byte
Ethernet (for programming)
Data transfer rate/distance MBit/s – 10 MBit/s, 100 m
Connection type – RJ45
Potential isolation – No
CANopen/easyNet
Data transfer rate/distance 500 kBit/s, 25 m
250 kBit/s, 60m
125 kBit/s, 125 m
50 kBit/s, 300 m
20 kBit/s, 700 m
10 kBit/s, 1000 m
500 kBit/s, 25 m
250 kBit/s, 60m
125 kBit/s, 125 m
50 kBit/s, 300 m
20 kBit/s, 700 m
10 kBit/s, 1000 m
Potential isolation
From power supply Yes Yes
From the inputs Yes Yes
From the outputs Yes Yes
Bus termination (first and last station) EASY-NT-R plug (incl. bus terminating resistor 120 Ω)
Connections 2 x RJ45, 8-pin 2 x RJ45, 8-pin
Control operating mode easyNet
Number of users 8 8
CANopen operating mode
Stations Number Max. 126 Max. 126
PDO type Asynchronous, cyclic, acyclic
Device profile To DS 301 V4 To DS 301 V4
Analog outputs
Number – –
Potential isolation
From power supply No No
From the digital inputs No No
From the digital outputs – –
To network easyNet, easyLink – –
Output type – –
Signal range V DC 0 - 10 0 - 10
Conversion time, analog/digital ms bit bit
