14/56 Automation products
I/O expansions IX/OC
2010 CA08103002Z-EN
Modular PLCs
ModularPLCsI/Oexpansions IX/OC
XIOC-NET-DP-M XIOC-NET-DP-S XIOC-NET-SK-M XIOC-SER XIOC-TC1
Interfaces
Interfaces PROFIBUS-DP, RS485,
EN 50170
PROFIBUS-DP, RS485,
EN 50170
RS485 RS232(C), RS422, RS485 RS232(C), RS422, RS485
Protocol PROFIBUS-DP master
(class 1)
PROFIBUS-DP slave Suconet K, K1 Transparent mode,
Modbus master/slave,
SUCOM-A, Suconet-K
slave
Tranparent mode,
Modbus Master/Slave,
SUCOM-A, DNP3
protocol
Character formats – – – 8E1, 8O1, 8N1, 8N2, 7E2,
7O2, 7N2, 7E1
8E1, 8O1, 8N1, 8N2, 7E2,
7O2, 7N2, 7E1
Control and signal cables – – – RTS, CTS, DTR, DSR,
DCD
RTS, CTS, DTR, DSR,
DCD
Transfer rate kbit/s 9.6 to 12000 9.6 to 12000 187.5, 375 0.3 …57.6
187.5, 375 (Suconet)
0.3 …57.6
Potential isolation Yes Yes Yes Yes (RS485, RS422) Yes (RS485, RS422)
Number of slaves 124 – 16 – –
Send/receive data 3500 Byte each Max. 244 Byte 250 Byte each 250 Byte per slave
120 Byte per slave
(Suconet-K slave)
250/500
Bus terminating resistors Switchable Switchable Switchable Switchable for RS485,
RS422
Switchable for RS485,
RS422
Connector type D-sub 9-pin socket D-sub 9-pin socket Plug-in terminal block RS232: D-sub 9-pin
RS485, 422: plug-in
terminal block
RS232: D-sub 9-pin
RS485, 422: plug-in
terminal block
Current consumption mA < 300 < 300 < 275 < 275 < 275
Weight kg Approx. 0.2 Approx. 0.2 Approx. 0.2 Approx. 0.2 Approx. 0.2
Number of modules XC100: 1
XC200: 3
XC100: 1
XC200: 3
XC100: 2
XC200: 4
XC100: 2
XC200: 4
XC200: 4
Slots 1, 2, 3 1, 2, 3 Any Any Any
