14/52 Automation products
I/O expansions XI/OC
2010 CA08103002Z-EN
Modular PLCs
ModularPLCsI/OexpansionsXI/OC
XIOC-8DO XIOC-16DO XIOC-16DO-S XIOC-32DO
Modules
Output type Transistor (source type)
Output voltage V DC 24 (-15…+20 %) 24 (-15…+20 %) 24 (-15…+20 %) 24 (-15…20 %)
Switching current, minimum mA 1 1 1 1
Leakage current mA 0.1 0.1 0.1 0.1
Maximum load current
Per circuit A 0.3 0.3 0.8 0.2
Per common potential terminal A 2.4 4 5 3.2
Output delay
OFF → ON ms ≦ 0.3 ≦ 0.3 ≦ 0.3 ≦ 0.3
OFF → ON ms ≦ 1 ≦ 1 ≦ 1 ≦ 1
Output channels Number 8 16 16 32
Channels with the same reference
potential
Number 8 16 16 32
Overvoltage protection Diode Diode Integrated Diode
Fuse rating A 4 8 None 8
Potential isolation With optocouplers
Indication LED (green) LED (green) LED (green) 16 LEDs (green),
switchable: 0 – 15, 16 – 31
Terminals Plug-in terminal block XIOC-TERM32
(connector and cable)
Internal current consumption (5 V DC) mA Normally 30 Normally 50 Normally 50 Normally 250
External voltage for outputs/module
(30 mA for module supply)
Us V 24 DC (-15/+20%) 24 DC (-15/+20%) 24 DC (-15/+20%) 24 DC (-15/+20%)
Short-circuit protection – – Yes –
Weight kg 0.16 0.16 0.16 0.16
XIOC-12DO-R
Modules
Output type Relays
Output voltage V DC 24
Output voltage V AC 100/240
Switching current, minimum mA 1
Maximum load current
Per circuit A 2
Per common potential terminal A 5
Output delay
OFF → ON ms ≦ 10
OFF → ON ms ≦ 10
Output channels Number 12
Channels with the same reference potential Number 12
Overvoltage protection External
Fuse rating A External
Potential isolation With optocouplers
Indication LED (green)
Terminals Plug-in terminal block
Internal current consumption (5 V DC) mA Normally 40
External voltage for operating the relay 24 V DC (-15 - +20%, max. 70 mA)
Weight kg 0.2
