Automation products
PLCs
2010 CA08103002Z-EN
Modular PLCs 14/49
ModularPLCsPLCs
XC-CPU201-EC256K-8DI-
6DO(-XV)
XC-CPU201-EC512K-8DI-
6DO(-XV)
XC-CPU202-EC4M-8DI-
6DO-XV
General
Standards IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
IEC/EN 61131-2
EN 50178
Ambient temperature °C 0 - +55 0 - +55 0 - +55
Storage °C -25 to +70 -25 to +70 -25 to +70
Mounting position Horizontal Horizontal Horizontal
Relative humidity, non-condensing (IEC/EN 60068-2-30) % 10 - 95 10 - 95 10 - 95
Air pressure (in operation) hPa 795 - 1080 795 - 1080 795 - 1080
Vibration resistance 10 - 57Hz ±0.075 mm
57 - 150 Hz ±1.0 g
10 - 57Hz ±0.075 mm
57 - 150 Hz ±1.0 g
10 - 57Hz ±0.075 mm
57 - 150 Hz ±1.0 g
Mechanical shock resistance 15 g/11 ms 15 g/11 ms 15 g/11 ms
Overvoltage category II II II
Pollution degree 2 2 2
Degree of protection IP20 IP20 IP20
Rated impulse withstand voltage Uimp V 850 850 850
Emitted interference EN 61000-6-4, Class A EN 61000-6-4, Class A EN 61000-6-4, Class A
Interference immunity EN 61000-6-2 EN 61000-6-2 EN 61000-6-2
Battery (lifespan) Normally 5 years Normally 5 years Normally 5 years
Weight kg 0.23 0.23 0.23
Terminals Plug-in terminal block Plug-in terminal block Plug-in terminal block
Terminal capacity
Screw terminals
Flexible with ferrule mm 2 0.5 - 1.5 0.5 - 1.5 0.5 - 1.5
Solid mm 2 0.5 - 2.5 0.5 - 2.5 0.5 - 2.5
Spring-cage terminal
Flexible mm 2 0.34 - 1.0 0.34 - 1.0 0.34 - 1.0
Solid mm 2 0.14 - 1.0 0.14 - 1.0 0.14 - 1.0
Electromagnetic compatibility (EMC) ￫Page 14/58
Power supply
Duration of mains failure ms 10 10 10
Repetition rate s 1 1 1
Input voltage V DC 24 24 24
Permissible range V DC 20.4…28.8 20.4…28.8 20.4…28.8
Input power W Max. 33 Max. 33 Max. 33
Ripple % ≦ 5 ≦ 5 ≦ 5
Maximum heat dissipation Pv W 6 6 6
Overvoltage protection Yes Yes Yes
Protection against polarity reversal Yes Yes Yes
Line filter Yes Yes Yes
Inrush current x In Not limited, (limiting only by a supply-side 24 V DC PSU)
Output voltage for signal modules
Rated value V DC 5 5 5
Output current A 3.2 3.2 3.2
Short-circuit rating Yes Yes Yes
Isolated from supply voltage No No No
CPU
Microprocessor NEC VR4181 A MIPS NEC VR4181 A MIPS ARM 532 MHz
Memory
Program code/program data 256 kByte/256 kByte 2 MB/512 kByte 4 MB/512 kByte
Marker/retain data kByte 16/32 16/32 16/64
Cycle time for 1 k of instructions (bits, bytes) ms < 0.15 < 0.15 < 0.025
