XVM-430-65TVB-1-11 XVM-450-65TVB-1-11 XVM-410-65TVB-1-11
Display
Screen diagonal/type 6.5" TFT LCD 6.5" TFT LCD 6.5" TFT LCD
Resolution VGA (640 x 480 pixel) VGA (640 x 480 pixel) VGA (640 x 480 pixel)
Visible screen area 132 mm x 99 mm 132 mm x 99 mm 132 mm x 99 mm
Color resolution (grayscale or color) 64k Colors 64k Colors 64k Colors
Backlight 2 CCFT cold cathode tubes 2 CCFT cold cathode tubes 2 CCFT cold cathode tubes
Lifespan of backlight Normally 50000 h Normally 50000 h Normally 50000 h
Resistive touch protective screen Touch sensor
(glass with membrane)
Touch sensor
(glass with membrane)
Touch sensor
(glass with membrane)
Operation
Technology Resistive touch Resistive touch Resistive touch
Keypad 31membrane keys with tactile
feedback, 4 status LEDs
31membrane keys with tactile
feedback, 4 status LEDs
31 membrane keys with tactile
feedback, 4 status LEDs
Operating elements 2acknowledgement keys (3-stage,
2-circuit), externally wired
Emergency switching off button
(2-circuit), externally wired
2acknowledgement keys (3-stage,
2-circuit), externally wired
Emergency switching off button
(2-circuit), externally wired
Keyswitch (3-position),
internally wired
Electronic hand wheel, internally
wired
2 acknowledgement keys (3-stage,
2-circuit), externally wired
Keyswitch (3-position),
internally wired
Electronic hand wheel,
internally wired
System
Processor RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz RISC, 32 bit, 400 MHz
Internal memory
DRAM (OS, program and data memory) Min. 64 MByte Min. 64 MByte Min. 64 MByte
FLASH Min. 64 MByte Min. 64 MByte Min. 64 MByte
NVRAM (Retain data) – – –
Operating system Windows CE Windows CE Windows CE
Engineering
Visualization software GALILEO GALILEO GALILEO
Interfaces, communication
Ethernet 100Base-TX/10Base-T 100Base-TX/10Base-T 100Base-TX/10Base-T
RS232 RS232-C RS232-C RS232-C
USB Host USB 1.1 (12 Mbit/s) USB 1.1 (12 Mbit/s) USB 1.1 (12 Mbit/s)
Power supply
Nominal voltage 24V DC 24V DC 24 V DC
Permissible voltage R.m.s.: 19.2 – 30.0 V DC R.m.s.: 19.2 – 30.0 V DC R.m.s.: 19.2 – 30.0 V DC
Voltage dips ≦ 10 ms ≦ 10 ms ≦ 10 ms
Input power 9.6 W 9.6 W 9.6 W
General
Front design Standard membrane
Membrane keypad with tactile
feedback
Standard membrane
Membrane keypad with tactile
feedback
Standard membrane
Membrane keypad with tactile
feedback
Degree of protection
Front IP65 IP65 IP65
Rear IP65 IP65 IP65
Approvals
Approvals cUL (UL508) cUL (UL508) cUL (UL508)
Applied standards and directives
Product standards EN 50178, EN 61131-2 EN 50178, EN 61131-2 EN 50178, EN 61131-2
Weight Approx. 1.3 kg Approx. 1.3 kg Approx. 1.3 kg
Environmental Conditions
Temperature
Operation 0 – 50°C 0 – 50°C 0 – 50°C
Storage/transport -20 – 70°C -20 – 70°C -20 – 70°C
Relative humidity 5 - 95%, non-condensing 5 - 95%, non-condensing 5 - 95%, non-condensing
Shock (IEC 60068-2-27) 25g/11ms 25g/11ms 25 g/11ms
Vibration (IEC 60068-2-6) 10Hz ≧ f > 57 Hz with 0.15 mm
9 Hz ≧ f > 150 Hz with 2 g
10Hz ≧ f > 57 Hz with 0.15 mm
9 Hz ≧ f > 150 Hz with 2 g
10 Hz ≧ f > 57 Hz with 0.15 mm
9 Hz ≧ f > 150 Hz with 2 g
