5/56 Contactor relays, contactors
Accessories
2010 CA08103002Z-EN
Accessories
For use with Part no. Price
See price
list
Std. pack Notes Information relevant for export to North America
Mechanical interlocks
Formechanically linking contactors
in combinations
0mm distance between contactors.
DILM7 - DILM72
DILA
DILM32-XVB
281227
50 Off – Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 012528
CSA Class No. 3211-05
NA Certification UL Recognized, CSA
certified
DILM80 - DILM170 DILM150-XVB
281226
10 Off – Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-03
NA Certification UL Listed, CSA certified
Mechanical interlocks
DILM7 - DILM15
DILMP20
DILA
DILM12-XMV
281196
1 Off For two contactors with AC or DC
operation arranged vertically or
horizontally.
Distance between contactors 0mm,
including contactor connector
Mechanical lifespan 2.5 x 106
operations.
DILM 150-XMV including mounting
plate for contactors.
Additional auxiliary contact
modules possible. ￫5/38
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 2411-03
NA Certification UL Listed, CSA certified
DILM17 - DILM38 DILM32-XMV
281197
DILM40 - DILM72 DILM65-XMV
281198
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 2411-03, 3211-04
NA Certification UL Listed, CSA certified
DILM80 - DILM170 DILM150-XMV
240081
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 012528
CSA Class No. 2411-03
NA Certification UL Listed, CSA certified
DILM185A,
DILM225A,
DILM250,
DILM300A,
DILM400,
DILM500,
DILM570
DILM500-XMV
208289
For contactors with the same or
different magnet systems mounted
horizontallyorvertically,mechanical
lifespan 5 x 106 operations. No
auxiliary contact permitted between
mechanical interlock and contactor.
Combination only with consecutive
installation sizes or DILM185A -
DILM570.
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2 No.
14-05; CE marking
UL File No. E29184
UL CCN NKCR
CSA File No. 012528
CSA Class No. 3211-04
NA Certification UL Listed, CSA certified
DILM580,
DILM650
DILM750,
DILM820
DILM1000
DILM820-XMV
208288
For contactors with the same or
different magnet systems mounted
horizontallyorvertically,mechanical
lifespan 5 x 106 operations. No
auxiliary contact permitted between
mechanical interlock and contactor.
DILM820-XMV consists of interlock
element and mounting plate.
Set of spare parts for
mechanical interlock
Ball for mechanical interlock, incl.
contactor connector.
– DILM80 - DILM170 DILM150-XMVE
107020
1 Off UL/CSA certification not required
DILM...-XDILM..-XVB, DILM..-XMV HPL05056EN
