Eaton Industrial Switchgear - xStart switching, protections and actuating motors

64 / 439

5/60 Contactor relays, contactors
Accessories
2010 CA08103002Z-EN
Accessories
For use with Part no. Price
See price
list
Std. pack Notes Information relevant for export to North
America
Three-phase commoning links
Protected against accidental contact,
short-circuit proof,
Ue = 690 V, Iu = 35 A
Can be extended by rotating by mounting
DILM7
DILM9
DILM12
DILM15
DILM12-XDSB0/3
240084
5 Off Suitable for 3 contactors.
Length 112 mm
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2
No. 14-05;
CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 012528
CSA Class No. 2411-03
NA Certification UL Listed,
CSA certified
DILM7
DILM9
DILM12
DILM15
DILM12-XDSB0/4
240085
Suitable for 4 contactors.
Length 157 mm
DILM7
DILM9
DILM12
DILM15
DILM12-XDSB0/5
240086
Suitable for 5 contactors.
Length 202 mm
Incoming connection block
– DILM7
DILM9
DILM12
DILM15
DILM12-XEK
240083
5 Off For three-phase commoning
link, protected against
accidental contact,
Ue = 690 V, Iu = 35 A.
Terminal capacities:
Stranded 2.5…16 mm2
Flexible with ferrule
2.5…16 mm 2
AWG14…8
Product Standards IEC/EN 60947-4-1;
UL 508; CSA-C22.2
No. 14-05;
CE marking
UL File No. E36332
UL CCN NLRV
CSA File No. 012528
CSA Class No. 2411-03
NA Certification UL Listed,
CSA certified
Adapter plate
Enables clipping on of switches on to DIN
rails
DILM80
DILM95
DILM115
DILM150
DILM170
NZM2-XC75
260215
1 Off For top-hat rail 75 mm Product Standards UL489; CSA-C22.2
No. 5-09; IEC60947,
CE marking
UL File No. E140305
UL CCN DIHS
CSA File No. 022086
CSA Class No. 1437-01
NA Certification UL Listed,
CSA certified
DILM12-XDSBS HPL05060EN
