5/54 Contactor relays, contactors
Suppressor circuit
2010 CA08103002Z-EN
SuppressorcircuitOrdering
Voltage For use with Circuit symbol Part no.
Article no.
Price
See price
list
Std. pack Notes
Us
V
Suppressor circuits
RC suppressors
24 - 48 AC DILM7 - DILM15
DILMP20
DILA
DILM12-XSPR48
281199
10 Off For AC operated contactors 50 - 60 Hz.
DC operated contactors and DILM115 and
DILM150 have an integrated suppressor.
Note drop-out delay. 110 - 240 AC DILM12-XSPR240
281200
240 - 500 AC DILM12-XSPR500
281201
24 - 48 AC DILM17 - DILM32
DILK12 - DILK25
DILL…
DILMP32 - DILMP45
DILM32-XSPR48
281202
110 - 240 AC DILM32-XSPR240
281203
240 - 500 AC DILM32-XSPR500
281204
24 - 48 AC DILM40 - DILM95
DILK33 - DILK50
DILMP63 - DILMP200
DILM95-XSPR48
281205
110 - 240 AC DILM95-XSPR240
281206
240 - 500 AC DILM95-XSPR500
281207
Varistor suppressors
24 - 48 AC DILM7 - DILM15
DILMP20
DILA
DILM12-XSPV48
281208
10 Off For AC operated contactors 50 - 60 Hz.
DC operated contactors and DILM115 and
DILM150 have an integrated suppressor.
Note drop-out delay. 48 - 130 AC DILM12-XSPV130
281209
130 - 240 AC DILM12-XSPV240
281210
240 - 500 AC DILM12-XSPV500
281211
24 - 48 AC DILM17 - DILM32
DILK12 - DILK25
DILL…
DILMP32 - DILMP45
DILM32-XSPV48
281212
48 - 130 AC DILM32-XSPV130
281213
130 - 240 AC DILM32-XSPV240
281214
240 - 500 AC DILM32-XSPV500
281215
24 - 48 AC DILM40 - DILM95
DILK33 - DILK50
DILMP63 - DILMP200
DILM95-XSPV48
281216
48 - 130 AC DILM95-XSPV130
281217
130 - 240 AC DILM95-XSPV240
281218
240 - 500 AC DILM95-XSPV500
281219
Information relevant for export to North America
Product Standards IEC/EN 60947-4-1; UL 508; CSA-C22.2 No. 14-05; CE marking
UL File No. E29096
UL CCN NLDX
CSA File No. 227038
CSA Class No. 3211-07
NA Certification UL Listed, CSA certified
A1
A2
A2
A1
DILM...-XSP... HPL05054EN
