Contactors
Contactor for capacitors
2010
CA08103002Z-EN
www.eaton.com5/127
Contactor forcapacitors
DILK12
DILK20
DILK25
DILK33
DILK50
General
Standards
IEC/EN 60947, VDE 0660
Ambient temperature
Open
°C
-25…60
-25…60
-25…60
-25…60
-25…60
Enclosed
°C
-25…40
-25…40
-25…40
-25…40
-25…40
Mounting position
Protection type
IP00
IP00
IP00
IP00
IP00
Protection against direct contact when
actuated from front (EN 50274)
Finger- and back-of-hand proof
Weight basic device
AC operated
kg
0.55
0.55
0.55
1
1
Terminal capacity of main cable
Solid
mm
2
1
x (0.75 - 16)
1
x (0.75 - 16)
1
x (0.75 - 16)
1
x (2.5 - 16)
1
x (2.5 - 16)
Flexible with ferrule
mm
2
1
x (0.75 - 16)
1
x (0.75 - 16)
1
x (0.75 - 16)
1
x (2.5 - 35)
1
x (2.5 - 35)
Stranded
mm
2
1
x 16
1
x 16
1
x 16
1
x (16 - 50)
1
x (16 - 50)
Solid or stranded
AWG 18 - 16
18 - 6
18 - 6
12 - 2
12 - 2
Flat conductor
Number of
layers x
width x
thickness
mm -
-
-
1
x (6 x 9 x 0.8)
1
x (6 x 9 x 0.8)
Group compensation
60
Hz
230
V
kvar
7.5
11
15
20
25
400
V
kvar
12.5
20
25
33.3
50
525
V
kvar
16.7
25
33.3
40
65
690
V
kvar
20
33.3
40
55
85
50/60
Hz
Open
230
V
I
e
A
18
29
38
50
72
400
V
I
e
A
18
29
38
50
72
525
V
I
e
A
18
29
38
50
72
690
V
I
e
A
18
29
38
50
72
Enclosed
230
V
I
e
A
16
26
34
45
65
400
V
I
e
A
16
26
34
45
65
525
V
I
e
A
16
26
34
45
65
690
V
I
e
A
16
26
34
45
65
Making capacity (i-peak value) without
damping
x I
e
180
180
180
180
180
Component lifespan
c (contacts)
x 10
6
0.15
0.15
0.15
0.15
0.15
Maximum operating frequency
Ops/h 120
120
120
120
120
180
°
90
°
90
°
90
˚
30
˚
30
˚
30
˚
DILK
