Contactors
Auxiliary contact modules
2010
CA08103002Z-EN
www.eaton.comAuxiliarycontactmodules
DILM7-… -
DILM38-…
DILA-
XHI(C)…(-S)
DILM32-
XHI(C)…(-S)
DILM150-
XHI…
DILM1000-XHI…
DILM820-XHI…
Auxiliary contact
Interlocked opposing contacts within an auxiliary
contact module (to IEC 60947-5-1 Annex L)
1)
-
Yes
Yes
Yes
Yes
Normally closed (not late-normally closed)
suitable as a mirror contact (to IEC/EN 60947-4-1,
Annex F)
DILM7 -
DILM38
DILM7 -
DILM38
DILM7 -
DILM38
DILM40 -
DILM170
DILM40 - DILM225A
DILM250 - DILM1000
Rated impulse withstand voltage
U
imp
V AC 6000
6000
6000
6000
6000
Overvoltage category/pollution degree
III/3
III/3
III/3
III/3
III/3
Rated insulation voltage
U
i
V AC 690
690
690
690
690
Rated operating voltage
U
e
V AC 500
500
500
500
500
Safe isolation according to EN 61140
Between coil and auxiliary contacts
V AC 400
400
400
440
440
Between the auxiliary contacts
V AC 400
400
400
440
440
Rated operational current
AC-15
230
V
I
e
A
4
4
4
4
4
380/415
V
I
e
A
4
4
4
4
4
500
V
I
e
A
1.5
–
1.5
1.5
1.5
DC L/R ≦ 15 ms
2)
24
V
I
e
A
10
10
10
10
10
60
V
I
e
A
6
6
6
6
6
110
V
I
e
A
3
3
3
3
3
220
V
I
e
A
1
1
1
1
1
DC-13 (6xP)
Contacts in series:
3
24
V
A
2.5
2.5
2.5
–
–
3
60
V
A
1
1
1
–
–
3
110
V
A
0.5
0.5
0.5
–
–
3
220
V
A
0.25
0.25
0.25
–
–
Conventional thermal current
I
th
A
10
16
16
16
10
Control circuit reliability (at U
e
= 24 V DC,
U
min
= 17 V, I
min
= 5.4 mA)
Fault
probability
λ
< 10
-8
,
< 1 one failure in 100 million operations
Component lifespan
at U
e
= 230 V, AC-15, 3 A
c (contacts) x 10
6
1.3
1.3
1.3
1.3
1.3
Short-circuit rating without welding
Max. fuse
A gG/gL 10
10
10
16
16
Notes
1)
Not with DIL…-XHIV and DIL…-XHICV.
2)
Switch-on and switch-off conditions based on DC-13, time constant as specified.
DILM..., DILA...
