Contactors

Paralleling link

2010

CA08103002Z-EN

5/133

Paralleling link

P1DILEM

DILM12-XP1

DILM32-XP1

DILM65-XP1

DILM150-XP1

DILM185-XP1

Parallel connector

Terminal capacity

Solid

mm

2

1 - 16

16

16

–

–

Flexible with ferrule

mm

2

1

x (0.5 - 25)

2

x (0.5 - 16)

1

x (16 - 35)

1

x (16 - 120)

–

–

Stranded

mm

2

1

x (0.5 - 25)

2

x (0.5 - 16)

1

x (16 - 50)

1

x (16 - 120)

1

x (35 - 300)

2

x (35 - 120)

–

Flat conductor

Number of

layers xwidth x

thickness

mm 6 x 9 x 0.8

–

–

2

x (11 x 21 x 1)

1

x (6 x 16 x 0.8)

2

x (20 x 32 x 0.5)

2

x (11 x 21 x 1)

Tightening torque

Nm 4

4

14

14

6

Terminal capacity of control

circuit cable

Solid

mm

2

–

–

–

–

1

x (0.75 - 4)

2

x (0.75 - 4)

Flexible with ferrule

mm

2

–

–

–

–

1

x (0.75 - 2.5)

2

x (0.75 - 2.5)

Tools

Pozidriv screwdriver

Size

2

2

–

–

–

Internal hexagon

SW

mm –

–

5

6

5

Conventional thermal current

3

pole

I

th

A

50

100

180

400

700

4

pole

I

th

A

60

–

–

–

–

P1SIL...M, DILM...-XP1
