5/128 Contactors
Contactor for capacitors
2010 CA08103002Z-EN
Magnet systems
Voltage tolerance
AC operated Pick-up x Uc 0.8 - 1.1 0.8 - 1.1 0.8 - 1.1 0.8 - 1.15 0.8 - 1.15
AC operated Drop-out x Uc 0.3 - 0.6 0.3 - 0.6 0.3 - 0.6 0.3 - 0.6 0.3 - 0.6
Power consumption of the coil in a cold state
and 1.0 x Uc
50 Hz Pick-up VA 58 58 58 45 45
50 Hz Sealing VA 7.6 7.6 7.6 1.5 1.5
50 Hz Sealing W 2.3 2.3 2.3 1.5 1.5
60 Hz Pick-up VA 71 71 71 45 45
60 Hz Sealing VA 9.3 9.3 9.3 1.5 1.5
60 Hz Sealing W 2.8 2.8 2.8 1.5 1.5
50/60 Hz Pick-up VA 65
59
65
59
65
59
45
45
45
45
50/60 Hz Sealing VA 9.6
7
9.6
7
9.6
7
1.5
1.5
1.5
1.5
50/60 Hz Sealing W 2.7
2.2
2.7
2.2
2.7
2.2
1.5
1.5
1.5
1.5
Duty factor % DF 100 100 100 100 100
Changeover times at 100 % Uc
(recommended values)
Main contacts
AC operated
Closing delay ms 16…22 16…22 16…22 50 50
Opening delay ms 8…14 8…14 8…14 40 40
Arcing time ms 10 10 10 10 10
Electromagnetic compatibility (EMC)
Emitted interference To EN 60947-1 To EN 60947-1 To EN 60947-1 To EN 60947-1 To EN 60947-1
Interference immunity To EN 60947-1 To EN 60947-1 To EN 60947-1 To EN 60947-1 To EN 60947-1
Further technical data
As per contactor DIL M17 M25 M32 M50 M65
DILK12 DILK20 DILK25 DILK33 DILK50
DILK
