Contactors
Basic devices up to 200 A, 4 pole
2010
CA08103002Z-EN
www.eaton.com5/125
Main contacts
Rated impulse withstand voltage
U
imp
V AC 8000
Overvoltage category/pollution degree
III/3
Rated insulation voltage
U
i
V AC 690
Rated operating voltage
U
e
V AC 690
Safe isolation according to EN 61140
Between coil and contacts
V AC 400
440
Between the contacts
V AC 400
440
Making capacity (cos ϕ to IEC/EN 60947)
To 690 V
A
144
238
350
560
700
1120 1330 1800
Breaking capacity
220/230
V
A
120
180
250
400
500
800
950
1150
380/400
V
A
120
180
250
400
500
800
950
1150
500
V
A
100
180
250
400
500
800
950
1150
660/690
V
A
70
120
144
250
296
650
750
800
Short-circuit rating
Short-circuit protection rating maximum fuse
Type “2” coordination
400
V
gG/gL 500 V A
20
35
35
63
80
160
160
250
690
V
gG/gL 690 V A
20
35
35
50
63
160
160
200
Type “1” coordination
400
V
gG/gL 500 V A
35
63
100
125
160
250
250
250
690
V
gG/gL 690 V A
25
50
50
80
80
200
200
200
AC voltage
AC-1 operation
Conventional thermal current 3 pole 50 - 60 Hz
Open
at 40 °C
I
th
A
22
32
45
63
80
125
160
200
at 50 °C
I
th
A
21
30
41
60
76
116
150
188
at 60 °C
I
th
A
20
28
39
54
69
108
138
172
Enclosed
I
th
A
18
27
36
50
64
100
128
160
Conventional thermal current, 1 pole
Open
I
th
A
60
84
117
162
207
325
415
516
Enclosed
I
th
A
54
76
105
146
186
292
373
464
Rated operational power
220/230
V
P
kW 8
12
16
23
29
45
58
72
240
V
P
kW 9
13
18
25
32
49
63
79
380/400
V
P
kW 14
20
28
39
50
78
100
125
415
V
P
kW 15
22
31
43
55
85
109
137
440
V
P
kW 16
23
33
46
58
90
116
145
500
V
P
kW 18
26
37
52
66
103
132
165
690
V
P
kW 24
35
49
68
87
136
174
217
AC-3 operation
Rated operational current AC -3 open,
50 – 60
Hz, 3 pole
220/230
V
I
e
A
12
18
25
40
50
80
95
115
240
V
I
e
A
12
18
25
40
50
80
95
115
380/400
V
I
e
A
12
18
25
40
50
80
95
115
415
V
I
e
A
12
18
25
40
50
80
95
115
440
V
I
e
A
12
18
25
40
50
80
95
115
500
V
I
e
A
10
18
25
40
50
80
95
115
660/690
V
I
e
A
7
12
15
25
32
65
80
93
Rated operational power
220/230
V
P
kW 3.5
5
7.5
12.5 15.5 25
30
37
240
V
P
kW 4
5.5
8.5
13.5 17
27.5 33
40
380/400
V
P
kW 5.5
7.5
11
18.5 22
37
45
55
415
V
P
kW 7
10
14.5 24
30
48
57
70
440
V
P
kW 7.5
10.5 15.5 25
32
51
60
75
500
V
P
kW 7
12
17.5 28
36
58
70
85
660/690
V
P
kW 6.5
11
14
23
30
63
75
90
DILMP20
DILMP32
DILMP63
DILMP125
DILMP45
DILMP80
DILMP160
DILMP200
DILMP20 ... DILMP200
