Contactors
Basic devices up to 200 A, 4 pole
2010
CA08103002Z-EN
www.eaton.comBasicdevicesup to 200A, 4pole
DILMP20
DILMP32
DILMP63
DILMP125
DILMP45
DILMP80
DILMP160
DILMP200
General
Standards
IEC/EN 60947, VDE 0660, UL, CSA
Lifespan, mechanical
AC operated
c (contacts)
x 10
6
10
DC operated
c (contacts)
x 10
6
10
Operating frequency, mechanical
Mechanical, AC operated
Operations/h
5000
3600
DC operated
Operations/h
5000
3600
Maximum operating frequency
Electrical (Contactor without overload relay)
600
Climatic proofing
Damp heat, constant, to IEC 60068-2-3
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open
°C
-25…60
Enclosed
°C
-25…40
Storage
°C
-40 - 80
Mounting position AC- and DC operated
Mechanical shock resistance (IEC/EN 60068-2-27)
Half-sinusoidal shock 10 ms
Main contacts
N/O
g
10
Auxiliary contacts
N/O
g
7
NC
g
5
Protection type
IP20
IP00
With accessories
–
IP20
Protection against direct contact when actuated from front (EN 50274)
Finger- and back-of-hand proof
Terminal type, screw connection
Terminal capacity of main cable
Solid
mm
2
1
x (0.75 - 4)
2
x (0.75 - 2.5)
1
x (0.75 - 16)
2
x (0.75 - 10)
1
x (2.5 - 16)
2
x (2.5 - 16)
–
Flexible with ferrule
mm
2
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
1
x (0.75 - 16)
2
x (0.75 - 10)
1
x (2.5 - 35)
2
x (2.5 - 25)
1
x (10 - 95)
2
x (10 - 70)
Stranded
mm
2
–
1
x 16
1
x (16 - 50)
2
x (16 - 35)
1
x (16 - 120)
2
x (16 - 95)
Solid or stranded
AWG 18 - 14
18 - 6
12 - 2
8 - 250
MCM
Flat conductor
Number of
layers x width x
thickness
mm –
–
2
x
(6
x 9 x 0.8)
2
x
(6
x 16 x 0.8)
Terminal capacity of control circuit cable
Solid
mm
2
1
x (0.75 - 4)
2
x (0.75 - 2.5)
1
x (0.75 - 4)
2
x (0.75 - 2.5)
1
x (0.75 - 4)
2
x (0.75 - 4)
1
x (0.75 - 4)
2
x (0.75 - 4)
Flexible with ferrule
mm
2
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
Solid or stranded
AWG 18 - 14
18 - 14
18 - 14
18 - 14
Main cable connection screw/bolt
M3.5
M5
M6
M10
Tightening torque
Nm 1.2
3
3.3
14
Control circuit cable connection screw/bolt
M3.5
M3.5
M3.5
M3.5
Tightening torque
Nm 1.2
1.2
1.2
1.2
Tools
Main conductors
Pozidriv screwdriver
Size
2
2
2
–
Internal hexagon
SW
mm –
–
–
5
Flat-blade screwdriver
mm 0.8 x 5.5
1
x 6
0.8
x 5.5
1
x 6
0.8
x 5.5
1
x 6
–
Auxiliary conductors
Pozidriv screwdriver
Size
2
2
2
2
Flat-blade screwdriver
mm 0.8 x 5.5
1
x 6
0.8
x 5.5
1
x 6
0.8
x 5.5
1
x 6
0.8
x 5.5
1
x 6
180
°
90
°
90
°
30
˚
30
˚
DILMP20 ... DILMP200
