Contactors
Illumination contactors
2010 CA08103002Z-EN
5/129
Illuminationcontactors
DILL12 DILL18 DILL20
General
Standards IEC/EN 60947, VDE 0660, UL, CSA
Lifespan, mechanical
AC operated c (contacts) x 106 1 1 1
Operating frequency, mechanical
Mechanical, AC operated Operations/h 60 60 60
Maximum operating frequency
Electrical Operations/h 60 60 60
Climatic proofing Damp heat, constant, to IEC 60068-2-78;
Damp heat, cyclic, to IEC 60068-2-30
Ambient
temperature
Open °C -25…60 -25…60 -25…60
Enclosed °C -25…40 -25…40 -25…40
Storage °C -40 - 80 -40 - 80 -40 - 80
Mounting position
Mechanical shock resistance (IEC/EN 60068-2-27)
Half-sinusoidal shock 10 ms 6.9 6.9 6.9
Protection type IP00 IP00 IP00
Weight
AC operated kg 0.42 0.42 0.42
Main contacts
Rated impulse withstand voltage Uimp V AC 8000 8000 8000
Overvoltage category/pollution degree III/3 III/3 III/3
Rated insulation voltage Ui V AC 690 690 690
Rated operating voltage Ue V AC 690 690 690
Making capacity A 238 350 550
Breaking capacity 380/400V A 170 250 320
Lifespan, electrical c (contacts) 10000 10000 10000
Short-circuit protection rating maximum fuse
400 V gG/gL 500 V A 63 100 125
AC voltage
AC-1 operation
Conventional thermal current
at 40 °C Ith A 27 40 45
at 60 °C Ith A 24 35 40
230 V Ie A 12 18 20
400 V Ie A 12 18 20
AC-1 operation
220/230 V Ie A 14 21 27
400 V Ie A 14 21 27
Electric lamps
Filament bulbs A 14 21 27
Mercury blended lamps A 12 16 23
Fluorescent lamp load
Conventional reactor starter
connection
A 20 26 35
Duo circuit A 20 26 35
Electronic upstream devices A 12 18 20
High-pressure mercury vapour lamps A 12 18 20
Metal-halide lamps A 12 18 20
High-pressure sodium lamps A 12 18 20
Low-pressure sodium lamps A 7.5 10 12
Maximum permissible compensation capacitance μF 470 470 470
Further technical data
As per contactor DIL M17 M25 M32
180
°
90
° 90
°
30 ˚ 30 ˚
DILL
