5/138 Contactors
Complete units for currents greater than 170 A
2010 CA08103002Z-EN
Complete units
DILM185A...DILM500
DILM250-S...DILM570-S
a DILM1000-XHI...-SI
b DILM1000-XHI11-SA
DILM580...DILM1000
a DILM820-XHI...-SI
b DILM820-XHI11-SA
c 8
f
b1
a1
M6
e
d1
b2 b3 b
d2
a
o11
a2
a
b
a
b
Part no. a a1 a2 b b1 b2 b3 d1 d2 e c f
DILM185A 140 120 160 180 160 165 190 20 41 5 158 83
DILM225A 140 120 160 180 160 165 190 20 41 5 158 83
DILM250 140 120 160 180 160 164 189 25 48 5 208 140
DILM300A 140 120 160 180 160 164 189 25 48 5 208 140
DILM400 160 130 180 200 180 184 209 25 48 6 216 140
DILM500 160 130 180 200 180 189 219 38 57 6 216 140
DILM570 160 130 180 200 180 189 219 38 57 6 216 140
250
80 d1
232
232
b3
140
b2
270
e
165
215
M6
a
a
b
b
f
Part no. b2 b3 d1 e f
DILM580 256 296 45 6 13.5
DILM650 256 296 45 6 13.5
DILM750 256 296 45 6 13.5
DILM820 256 296 45 6 13.5
DILM1000 256 296 45 10 13.5
