Powercontactorswith terminal shroud,mechanical interlockContactors with terminal shrouds
DILM250...DILM1000 + DILM...-XHB DILM250 + Z5-.../FF250
DILM185A...DILM225A + DILM225A-XHB
Contactor with star-point bridge and terminal shroud
DILM...XS1
Mechanical interlock
DILM500-XMV DILM820-XMV
a
b
150
34
523
110
328
~144
for part no. a b
DILM250, DILM300A 150 384
DILM400 150 404
DILM500 174 426
DILM580...1000 236 506
325
124
140
a
b
for part no. a b
DILM185...250 150 127
DILM300...400 150 137
DILM500 176 146
a
for part no. a
DILM185...500 15
9
515
430
270300
20
...DILM
