6/2

Overload Relays

Overload relays, CT-operated overload relays

2010

CA08103002Z-EN

Overload relays,CT-operatedoverload relays

Technical overview

Electronicoverload relays, thermistoroverload relay formachineprotection

Setting ranges (A)

(

note max. current of the contactor)

DILEM

DILM7 DILM12

DILM17 DILM32

DILM40 DILM65

DILM80 DILM150

DILM9 DILM15

DILM25 DILM38

DILM50 DILM72

DILM95 DILM170

DILM115

Overload relays

ZE

0.1-12

ZB12

0.1-16

ZB32

0.1-38

ZB65

6-75

ZB150

35-175

Z5-.../FF225A

70-250

Z5-.../FF250

50-300

Current transformer-operated overload relay

ZW7-...

42-630
