Overload relays
Bimetal relays for mini-contactor relays
2010
CA08103002Z-EN
www.eaton.comBimetal relays formini-contactor relays
Ordering
Setting range of
overload
releases
Circuit symbol
Auxiliary contact
For use with
Short-circuit protection
N/O=normallyopencontact
NC=normallyclosedcontact
Type “1”
coordination
Type “2”
coordination
I
r
gG/gL
gG/gL
A
A
A
ZE overload relays for mini contactor relays
•
Phase failure sensitivity to IEC/EN 60947, VDE 0660 Part 102
•
Test/off pushbutton
•
Reset pushbutton manual/auto
•
Trip-free release
•
Direct mounting
0.1 – 0.16
1
N/O 1 NC
DILEM
DIULEM/21/MV
SDAINLEM
20
0.5
0.16 – 0.24
1
0.24 – 0.4
2
0.4 – 0.6
2
0.6 – 1
4
1 – 1.6
6
1.6 – 2.4
6
2.4 – 4
10
4 – 6
6 – 9
9 – 12
Information relevant for export to North America
Product Standards
UL 508; CSA-C22.2 No. 14; IEC/EN 60947-4-1; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
12528
CSA Class No.
3211-03
NA Certification
UL Listed, CSA certified
Suitable for
Branch circuits
Max. Voltage Rating
600
V AC
Degree of Protection
IEC: IP20, UL/CSA Type: -
See also
￫Page 6/29
2 4 6 98 96
97 95
ZE
HPL06006EN
