Overload relays
Overload relays up to 150A
Part no.
Article no.
Price
See price
list
Std. pack Notes
ZB12-0,16
278431
1 Off Overload release: tripping class 10 A
Short-circuit protection: With direct mounting,
observe the maximum permissible fuse of the
contactor.
Suitable for protection of EEx e motors.
II (2) GD
PTB 04 ATEX 3022
Observe manual AWB2300-1527D/GB.
• Phase failure sensitivity to IEC/EN 60947, VDE 0660
Part 102
• Test/off pushbutton
• Reset pushbutton manual/auto
• Trip-free release
• Direct mounting
Fitted directly to the contactor
1 Contactor ￫Chapter 5
Accessories ￫Page 6/26
Manual ￫Page 6/26
ZB12-0,24
278432
ZB12-0,4
278433
ZB12-0,6
278434
ZB12-1
278435
ZB12-1,6
278436
ZB12-2,4
278437
ZB12-4
278438
ZB12-6
278439
ZB12-10
278440
ZB12-12
278441
ZB12-16
290168
ZB32-0,16
278442
1 Off Overload release: tripping class 10 A
Short-circuit protection: With direct mounting,
observe the maximum permissible fuse of the
contactor.
Suitable for protection of EEx e motors.
II (2) GD
PTB 04 ATEX 3022
Observe manual AWB2300-1527D/GB.
• Phase failure sensitivity to IEC/EN 60947, VDE 0660
Part 102
• Test/off pushbutton
• Reset pushbutton manual/auto
• Trip-free release
• Direct mounting
ZB32-0,24
278443
ZB32-0,4
278444
ZB32-0,6
278445
ZB32-1
278446
ZB32-1,6
278447
ZB32-2,4
278448
ZB32-4
278449
ZB32-6
278450
ZB32-10
278451
ZB32-16
278452
ZB32-24
278453
ZB32-32
278454
ZB32-38
112474
1
Fitted directly to the contactor Separate mounting
1 Contactor ￫Chapter 5
2 Base ￫Page 6/26
Manual ￫Page 6/26
1 1
