107 / 439
Mini contactor relays
2010
CA08103002Z-EN
www.eaton.com5/103
DILEEM
DILEM
DILEM12
DILEEM-G
DILEM-G
DILEM12-G
DILEM4
DILEM4-G
General
Standards
IEC/EN 60947, VDE 0660, CSA, UL
Lifespan, mechanical; Coil 50/60 Hz
at 50 Hz
7
–
7
–
Lifespan, mechanical
c (contacts)
x 10
6
10
20
20
–
Maximum operating frequency
Mechanical
Ops/h 9000
Electrical (Contactor without overload relay)
￫Characteristic curves Page 5/95
Climatic proofing
Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open
°C
-25 - 50
Enclosed
°C
-25 - 40
Mounting position
Mechanical shock resistance (IEC/EN 60068-2-27)
Half-sinusoidal shock 10 ms
Basic device without auxiliary contact mod-
ule
Main circuit normally open
contact
g
10
Auxiliary contacts
NC/Normally open contact
g
10/8
10/8
–
–
Basic devices with auxiliary contact module
Main circuit normally open
contact
g
10
AuxiliarycontactsNormally
open contact/NC
g
20/20
Protection type
IP20
Protection against direct contact when actuated from front
(
EN 50274)
Finger- and back-of-hand proof
Weight
kg
0.2
0.17
0.2
0.17
Terminal capacity: main and auxiliary contacts
Solid
mm
2
1
x (0.75 - 2.5)
2
x (0.75 - 2.5)
Flexible with ferrule
mm
2
1
x (0.75 - 1.5)
2
x (0.75 - 1.5)
Solid or stranded
AWG 18 - 14
Terminal screw
M3.5
Pozidriv screwdriver
Size
2
Flat-blade screwdriver
mm 0.8 x 5.5
1
x 6
Max. tightening torque
Nm 1.2
Terminal capacity springloaded terminals main and control
circuits
Solid
mm
2
1
x (1 - 2.5)
2
x (1 - 2.5)
Flexible with ferrule
mm
2
1
x (1 - 2.5)
2
x (1 - 2.5)
Flat-blade screwdriver
mm 0.6 x 3.5
Any, except for vertically with terminals A1/A2 below
A2
A1
DILEEM, DILEM
