Mini contactor relays
2010
CA08103002Z-EN
www.eaton.comDILE(E)M(-12)...
…
DILEM
Auxiliary contact
Interlocked opposing contacts to EN 60947-5-1 Annex L, including
auxiliary contact module
Yes
Yes
Rated impulse withstand voltage
U
imp
V AC 6000
6000
Overvoltage category/pollution degree
III/3
III/3
Rated insulation voltage
U
i
V AC 690
690
Rated operating voltage
U
e
V AC 600
600
Safe isolation according to EN 61140
Between coil and auxiliary contacts
V AC 300
300
Between the auxiliary contacts
V AC 300
300
Rated operational current
AC-15
220/240
V
I
e
A
6
4
380/415
V
I
e
A
3
2
500
V
I
e
A
1.5
1.5
DC
L/R ≦ 15 ms
Contacts in series:
1
24
V
A
2.5
2.5
2
60
V
A
2.5
2.5
3
100
V
A
1.5
1.5
3
220
V
A
0.5
0.5
Conventional thermal current
I
th
A
10
10
Control circuit reliability (at U
e
= 24 V DC, U
min
= 17 V, I
min
= 5.4 mA) Fault
probability
λ
<10
--8
,
< one failure in 100 million operations
Component lifespan at U
e
= 240 V
AC-15
c (contacts) x 10
6
0.2
0.2
DC
1)
L/R = 50 ms: 2 contacts in series at I
e
= 0.5 A
c (contacts) x 10
6
0.15
0.15
Short-circuit rating without welding
Maximum overcurrent protective device
PKZM0-4
PKZM0-4
Short-circuit protection rating maximum fuse
500
V
A gG/gL 6
6
500
V
A fast
10
10
Current heat loss at load of I
th
Per contact
W 0.2
0.2
Notes
1)
Switch-on and switch-off conditions based on DC-13, time constant as
specified
DILEEM, DILEM
