5/110 Contactors
Basic devices up to 170 A
2010 CA08103002Z-EN
DILM7 DILM9 DILM12 DILM15 DILM17 DILM25
General
Main cable connection screw/bolt M3.5 M3.5 M3.5 M3.5 M5 M5
Tightening torque Nm 1.2 1.2 1.2 1.2 3.2 3.2
Control circuit cable connection screw/bolt M3.5 M3.5 M3.5 M3.5 M3.5 M3.5
Tightening torque Nm 1.2 1.2 1.2 1.2 1.2 1.2
Tools
Main conductors
Pozidriv screwdriver Size 2 2 2 2 2 2
Internal hexagon SW mm – – – – – –
Flat-blade screwdriver mm 0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
Auxiliary conductors
Pozidriv screwdriver Size 2 2 2 2 2 2
Flat-blade screwdriver mm 0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
0.8 x 5.5
1 x 6
Terminal type spring-cage terminal
Terminal capacity of main cable
Solid mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
– –
Flexible mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
– –
Flexible with ferrule mm 2 1 x (0.75 - 1.5)
2 x (0.75 - 1.5)
– –
Flexible without ferrule mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
– –
Solid or stranded AWG 18 - 14 18 - 14 18 - 14 18 - 14 – –
Terminal capacity of control circuit cable
Solid mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
Flexible mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
Flexible with ferrule mm 2 1 x (0.75 - 1.5)
2 x (0.75 - 1.5)
Flexible without ferrule mm 2 1 x (0.75 - 2.5)
2 x (0.75 - 2.5)
– –
Solid or stranded AWG 18 - 14 18 - 14 18 - 14 18 - 14 18 - 14 18 - 14
Tools
Strip length mm 10 10 10 10 10 10
Screwdriver blade width mm 3.5 3.5 3.5 3.5 3.5 3.5
Main contacts
Rated impulse withstand voltage Uimp V AC 8000 8000 8000 8000 8000 8000
Overvoltage category/pollution degree III/3 III/3 III/3 III/3 III/3 III/3
Rated insulation voltage Ui V AC 690 690 690 690 690 690
Rated operating voltage Ue V AC 690 690 690 690 690 690
Safe isolation according to EN 61140
Between coil and contacts V AC 400 400 400 400 440 440
Between the contacts V AC 400 400 400 400 440 440
Making capacity (cos ϕ to IEC/EN 60947) To 690 V A 112 112 144 155 238 350
Breaking capacity
230 V A 70 90 120 124 170 250
380/400 V A 70 90 120 124 170 250
500 V A 50 70 100 100 170 250
660/690 V A 40 50 70 70 120 150
Short-circuit rating
Short-circuit protection rating maximum fuse
Type “2” coordination
400 V gG/gL 500 V A 20 20 20 20 35 35
690 V gG/gL 690 V A 16 16 20 20 35 35
Type “1” coordination
400 V gG/gL 500 V A 35 35 35 63 63 100
690 V gG/gL 690 V A 20 20 25 50 50 50
DILM7 ... DILM170
