5/116 Contactors
Comfort devices and standard devices greater than 170 A
2010 CA08103002Z-EN
Comfortdevicesand standarddevices greater than 170A
Contactors
DILM185A DILM225A DILM250 DILM300A DILM400 DILM500 DILM570
General
Standards IEC/EN 60947, VDE 0660, UL, CSA
Lifespan, mechanical
AC operated c (contacts) x 106 10 10 10 10 7 7 7
DC operated c (contacts) x 106 10 10 10 10 7 7 7
Operating frequency, mechanical
AC operated Operations/h 3000 3000 3000 3000 2000 2000 2000
DC operated Operations/h 3000 3000 3000 3000 2000 2000 2000
Maximum operating frequency
Electrical (Contactor without overload relay) ￫Engineering Page 5/95
Climatic proofing Damp heat, constant, to IEC 60068-2-78
Damp heat, cyclic, to IEC 60068-2-30
Ambient temperature
Open °C -25…60 -25…60 -25…60 -25…60 -25…60 -25…60 -25…60
Enclosed °C -25…40 -25…40 -25…40 -25…40 -25…40 -25…40 -25…40
Storage °C -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80 -40 - 80
Mounting position: AC and DC-actuated
Mechanical shock resistance (IEC/EN 60068-2-27)
Half-sinusoidal shock 10 ms
Main contacts
N/O g 10 10 10 10 10 10 10
Auxiliary contacts
N/O g 10 10 10 10 10 10 10
NC g 8 8 8 8 8 8 8
Protection type IP00 IP00 IP00 IP00 IP00 IP00 IP00
Protection against direct contact when actuated
from front (EN 90274)
Finger- and back-of-hand proof with cover or terminal block
Weight
Weight kg 3.2 3.2 6.5 6.5 8 8 8
Terminal capacity of main cable
Flexible with cable lug mm2 50 - 185 50 - 185 50 - 240 50 - 240 50 - 240 50 - 240 50 - 240
Stranded with cable lug mm2 50 - 185 70 - 185 70 - 240 70 - 240 70 - 240 70 - 240 70 - 240
Solid or stranded AWG 1/0 - 350
MCM
2/0 - 250
MCM
2/0 - 500
MCM
2/0 - 500
MCM
2/0 - 500
MCM
2/0 - 500
MCM
2/0 - 500
MCM
Busbar Width mm 32 32 25 25 25 30 30
Main cable connection screw/bolt M10 M10 M10 M10 M10 M10 M10
Tightening torque Nm 24 24 24 24 24 24 24
Terminal capacity of control circuit cable
Solid mm2 1x (0.75 - 2.5)
2x (0.75 - 2.5)
Flexible with ferrule mm2 1x (0.75 - 2.5)
2x (0.75 - 2.5)
Solid or stranded AWG 2 x (18 - 12) 2 x (18 - 12) 2 x (18 - 12) 2 x (18 - 12) 2 x (18 - 12) 2 x (18 - 12) 2 x (18 - 12)
Control circuit cable connection screw/bolt M3.5 M3.5 M3.5 M3.5 M3.5 M3.5 M3.5
Tightening torque Nm 1.2 1.2 1.2 1.2 1.2 1.2 1.2
Tools
Main conductors
Wrench mm 16 16 16 16 16 16 16
Auxiliary conductors
Pozidriv screwdriver Size 2 2 2 2 2 2 2
180
°
90° 90° 30 ˚ 30˚
DILM185...DILM1600, DILH
