5/118 Contactors
Comfort devices and standard devices greater than 170 A
2010 CA08103002Z-EN
Main contacts
Rated impulse withstand voltage Uimp V AC 8000 8000 8000 8000 8000 8000 8000
Overvoltage category/pollution degree III/3 III/3 III/3 III/3 III/3 III/3 III/3
Rated insulation voltage Ui V AC 1000 1000 1000 1000 1000 1000 1000
Rated operating voltage Ue V AC 1000 1000 1000 1000 1000 1000 1000
Safe isolation according to EN 61140
Between coil and contacts V AC 500 500 500 500 500 500 500
Between the contacts V AC 500 500 500 500 500 500 500
Making capacity (cos ϕ to IEC/EN 60947) A 2700 2700 3000 3600 5500 5500 6000
Breaking capacity
220/230 V A 2250 2250 2500 3000 5000 5000 5800
380/400 V A 2250 2250 2500 3000 5000 5000 5800
500 V A 2250 2250 2500 3000 5000 5000 5800
660/690 V A 2250 2250 2500 3000 5000 5000 5800
1000 V A 760 760 760 950 950 950 950
Component lifespan ￫Page 5/91
Short-circuit rating
Short-circuit protection rating maximum
fuse
Type “2” coordination
400 V gG/gL 500 V A 250 250 315 315 500 500 500
690 V gG/gL 690 V A 250 250 315 315 500 500 500
1000 V gG/gL 1000 V A 160 160 160 160 200 200 200
Type “1” coordination
400 V gG/gL 500 V A 400 400 400 400 630 630 800
690 V gG/gL 690 V A 315 315 400 400 630 630 630
1000 V gG/gL 1000 V A 200 200 200 200 250 250 250
AC voltage
AC-1 operation
Conventional thermal current 3 pole 50 - 60 Hz
Open
at 40 °C Ith A 337 356 400 430 612 857 920
at 50 °C Ith A 301 310 360 385 548 767 821
at 55 °C Ith A 287 295 340 365 522 731 783
at 60 °C Ith A 275 285 330 350 500 700 750
Enclosed1) Ith A 245 275 300 315 450 650 –
Conventional thermal current, 1-pole
Open1) Ith A 685 707 825 875 1250 1750 1875
Enclosed1) Ith A 625 636 742 785 1125 1600 –
AC-3 operation
Rated operational current AC -3 open,
50 – 60 Hz, 3 pole
220/230 V Ie A 185 225 250 300 400 500 580
240 V Ie A 185 225 250 300 400 500 580
380/400V Ie A 185 225 250 300 400 500 580
415 V Ie A 185 225 250 300 400 500 580
440 V Ie A 185 225 250 300 400 500 580
500 V Ie A 185 225 250 300 400 500 500
660/690V Ie A 150 160 250 210 360 360 360
1000 V Ie A 76 76 76 95 95 95 95
Rated operational power
220/230 V P kW 55 70 75 90 125 155 185
240 V P kW 62 75 85 100 132 170 200
380/400V P kW 90 110 132 160 200 250 315
415 V P kW 110 132 148 180 240 300 348
440 V P kW 115 138 132 185 200 250 370
500 V P kW 132 160 180 215 290 360 360
660/690V P kW 140 150 240 195 344 344 344
1000 V P kW 108 108 108 132 132 132 132
Notes 1) At maximum permissible ambient air temperature
2) To 690 V
Contactors
DILM185A DILM225A DILM250 DILM300A DILM400 DILM500 DILM570
DILM185...DILM1600, DILH
