www.eaton.comAmplifiermodules,electronic timermodule,contactormonitoringdevice
ETS4-VS3
DILM32-XTE
CMD(24VDC)
CMD(220-240VAC)
Magnet systems
Voltage tolerance
Starting voltage
AC operated
Pick-up
x U
c
–
0.85 - 1.1
0.85 - 1.1
DC operated
1)
Pick-up
x U
c
0.85 - 1.2
0.7 - 1.2
0.85 - 1.1
Power consumption
AC operated
Sealing
VA
–
2
4
AC operated
Sealing
W –
1.8
4
DC operated
Pick-up =
sealing
W 0.6
–
4
Duty factor
%
DF
100
100
100
Changeover times at 100 % U
c
(
recommended values)
DC operated closing delay
ms
7
–
–
DC operated opening delay
ms
3
–
–
Maximum operating frequency
Max. operating frequency
Ops/h –
3600
–
6
A/250 V
Ops/h –
360
–
Minimum on duration
On-delayed
ms
–
< 50
–
Off-delayed
ms
–
< 200
–
Repetition accuracy (with constant parameters)
Deviation
% –
< 5
–
Recovery time (after 100% time delay)
ms
–
70
–
Contact changeover time
DILM32-XTEE11/DILM32-XTED11
t
u
ms
–
10
–
DILM32-XTEY20
t
u
ms
–
50
–
CMD
t
u
ms
–
–
100
± 20%
Notes
1)
Smoothed DC, three-phase bridge rectifier or smoothed two-phase
bridge rectifier
ETS-VS3, DILM, CMD
